Owner’s Manual Model DCS19W IMPORTANT SAFETY INFORMATION: Always read this manual first before attempting to install or use this stove. For your safety, always comply with all warnings and safety instructions contained in this manual to prevent personal injury or property damage. To view the full line of Dimplex products, please visit www.dimplex.
Table of Contents Welcome & Congratulations . . . . . . . . 3 Important Instructions. . . . . . . . 4 Quick Reference Guide. . . . . . . . . . . . . 6 Stove Installation . . . . . . . . . . . . . . . . . 6 Operation. . . . . . . . . . . . . . . . . . . . . . . . 8 Maintenance. . . . . . . . . . . . . . . . . . . . . . 9 Warranty. . . . . . . . . . . . . . . . . . . . . . . .
Welcome & Congratulations Thank you and congratulations for choosing to purchase an electric stove from Dimplex, the world leader in electric heat. Please carefully read and save these instructions. CAUTION: Read all instructions and warnings carefully before starting installation. Failure to follow these instructions may result in a possible electric shock, fire hazard and will void the warranty.
Important Instructions ① Read all instructions before using this appliance. ② This stove is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. The trim around the heater outlet becomes hot during heater operation. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes, and curtains at least 3 feet (0.9 m) from the front of the heater and keep them away from the sides and rear. ③ Do not use on elevated surfaces.
Important Instructions (one blade is wider than the other). This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician to install the proper outlet. Do not change the plug in any way. This heater is not intended for use with an extension cord. Plug the cord directly into an appropriate wall receptacle.
Quick Reference Guide ① The information regarding the model of your electric stove can be found on the label located on the back of the unit. ② If you have any technical questions or concerns regarding the operation of your electric stove, or require service contact customer service. Stove Installation Warning: This stove is not to be used on elevated surfaces. Site Selection ! NOTE: A 15 Amp, 120 Volt alternating current (VAC) circuit is required.
Stove Installation other applicable regulations to reduce the risk of fire, electric shock and injury to persons. Do not attempt to wire your own new outlets or circuits. To reduce the risk of fire, electric shock or injury to persons, always use a licensed electrician. heater is not intended for use with an extension cord. Installation ① Remove all packaging from unit and ensure heater exhaust is free from debris and packaging remnants. ② Place unit on floor in desired location.
Operation This section will describe each convenient control, located on the back of the stove (Figure 1). Figure 1 A B C A. Main On/Off Switch Controls the electricity supply to the stove and activates the flame effect only when on. B. Low Heat On/Off Switch Provides 650 Watt heat output. C. High Heat On/Off Switch Provides 1300 Watt heat output with the Low Heat Switch. ! NOTE: The Main On/Off Switch must be set to On for the Low Heat or High Heat Switch to operate.
Maintenance WARNING: Disconnect power before attempting any maintenance or cleaning to reduce the risk of fire, electric shock or damage to persons. Light Bulb Replacement Allow at least five (5) minutes for the light bulb and heater to cool off before touching the bulb to avoid accidental burning of skin. The light bulbs will need to be replaced when the flame effect is no longer visible. There are two (2) bulbs under the ember bed which generate the flames and embers.
Maintenance these can be removed by dusting lightly with a clean dry cloth. To remove fingerprints or other marks, the front glass panel can be cleaned with a damp cloth. The front glass panel should be completely dried with a lint free cloth to prevent water spots. To prevent scratching, do not use abrasive cleaners or spray liquids on the clear door surface. Surface Cleaning Use warm water only to clean painted surfaces of the stove. Do not use abrasive cleaners.
Warranty Products to which this limited warranty applies 90 days from the date of the first purchase of such product. This limited warranty applies to the following models of your newly purchased Dimplex electric stove DCS19W. This limited warranty applies only to purchases made in any province of Canada except for Yukon Territory, Nunavut, or Northwest Territories or in any of the 50 States of the USA (and the District of Columbia) except for Hawaii and Alaska.
Warranty • Dimplex will in its sole discretion replace such defective part(s) without charge, or if part replacement proves not to be commercially practicable or cannot be timely made, Dimplex may, in lieu of replacing part(s) choose to replace the unit. • This limited warranty does not entitle the purchaser to on-site or in-home services. On-site or in-home services may be performed at the purchaser’s specific request and expense at Dimplex's then-current rates for such services.
Dimplex North America Limited 1367 Industrial Road Cambridge ON Canada N1R 7G8 © 2011 Dimplex North America Limited 13
