= -60V : R

SAT

= 39m ; I

= -5.5A

DESCRIPTION

Packaged in the SOT223 outline this new low saturation 60V PNP transistor

offers extremely low on state losses making it ideal for use in DC-DC circuits

and various driving and power management functions.

FEATURES

•

Extremely low equivalent on-resistance; R

SAT

= 39mV at 5A

•

5.5 amps continuous current

•

Up to 15 amps peak current

•

Very low saturation voltages

•

Excellent gain characteristics specified up to 10 Amps

APPLICATIONS

•

DC - DC converters

•

MOSFET gate drivers

•

Charging circuits

•

Power switches

•

Motor control

DEVICE MARKING

ZXTP

2012

ZXTP2012G

ISSUE 1 - JUNE 2005

60V PNP MEDIUM POWER LOW SATURATION TRANSISTOR IN SOT223

DEVICE REEL

SIZE

TAPE

WIDTH

QUANTITY PER

REEL

ZXTP2012GTA 7” 12mm

embossed

1,000 units

ZXTP2012GTC 13” 4,000 units

ORDERING INFORMATION

PINOUT

TOP VIEW
