MAVIC AIR
Aircraft The DJITM MAVICTM Air features a new folding design and a fully stabilized 3-axis gimbal camera capable of shooting 4K video and 12 megapixel photos. DJI signature technologies such as Obstacle Avoidance and Intelligent Flight Modes like SmartCapture, Panorama, Advanced Pilot Assistance Systems, QuickShot, ActiveTrackTM, and TapFlyTM, make capturing complex shots effortless and easy. The Mavic Air boasts a maximum flight speed of 42.5 mph (68.4 kph) and a maximum flight time* of 21 minutes. 1.
9. Intelligent Flight Battery * Maximum flight time was tested in 0 wind at a consistent 15.5 mph (25 kph). This value should be taken for reference only. ** The Forward, Downward and Backward Vision Systems are affected by surrounding conditions. Read the Disclaimer and Safety Guidelines and watch the tutorial in the DJI GO 4 app or on the Official DJI website to learn more. http://www.dji.
13. Gimbal Dial 1315 14. Record Button 1416 15. Customizable Button 16. Shutter Button GNSS GPS / GLONASS Operating Frequency 2.4-2.4835 GHz; 5.725-5.850 GHz Transmitter Power EIRP 2.4 GHz: 28 dBm (FCC), 19 dBm (CE), 19 dBm (SRRC) 19 dBm (MIC ) 5.
Supported SD Cards ● microSD. Class 10 or UHS-1 rating required. Remote Controller Dimensions 143.9×78.3×61.2 mm (Folded) Operating Frequency 2.4-2.4835 GHz; 5.725-5.850 GHz Max Transmission Distance 2.4 GHz: FCC: 2.5 mi (4 km); CE/SRRC/MIC: 1.2 mi (2 km) 5.8 GHz: FCC: 2.5 mi (4 km); CE: 0.3 mi (0.5 km) SRRC: 1.6 mi (2.5 km) (Unobstructed and free of interference) Operating Temperature Battery Transmitter Power 32° to 104° F (0° to 40° C) 2970 mAh 2.
USB-C Power Adapter Voltage 13.2 V Rated Power 50 W Intelligent Flight Battery Capacity 2375 mAh Voltage 11.55 V, Max 13.2 V Battery Type LiPo 3S Energy 27.43 Wh Net Weight Approx.140 g Charging Temperature Range 41° to 104° F (5° to 40° C) Max Charging Power 60 W For more information, read the User Manual: http://www.dji.
※This content is subject to change without prior notice. 1. Downloading the DJI GO 4 App and Watching Tutorial Videos Search for ‘DJI GO 4’ in the App Store or Google Play, or scan the QR code to download the app on your mobile device. DJI GO 4 protector from the arms and landing camera. gears. It is recommended to mount the propeller guards when flying in Beginner Mode or indoors to ensure better safety. Refer to the Mavic Air Propeller Guards User Guide to learn more.
● Ensure the landing gear is properly unfolded before use. Otherwise, the built-in antenna may be affected causing serious problems to the video link. Make sure you fold the landing gears first before folding the aircraft arms. 3. Charging the Batteries Use the provided charger to full charge the Intelligent Flight Battery before first time use.
Press once to check the battery level. Press once, then again and hold to turn on/off. level. Press once, then again and hold to turn on/off the remote controller. Press the Power button once to check the current battery 4. Preparing the Remote Controller mobile device clamps, controller cable to the end of the then attach the control sticks. the slot on the side of the device within clamps.
controller Use your DJI account to activate the aircraft. Activation requires an internet connection. Internet 6. Flight Before taking off, make sure the Aircraft Status (GPS) Bar in the DJI GO 4 app displays ‘Ready to Go’.
● Controlling flight with Virtual Joysticks on your mobile device via Wi-Fi
DJI GO 4 App Mavic_XXX 1. Power on the aircraft. 2. Press and hold the Function Button on the aircraft for four seconds until you hear a double beep, switching to Wi-Fi control mode. 3. Launch the DJI GO 4 app and tap the icon in the top right corner of your 4. Tap Auto Takeoff. 5. Now you can fly the aircraft with touch control via Virtual Joysticks.
TapFly Tripod SmartCapture ● Watch the tutorial in the DJI GO 4 app or on the Official DJI website to learn more. ● Always set an appropriate RTH altitude before takeoff. When the aircraft is returning to the Home Point, you should guide it with the control sticks. 7. Fly Safe Fly in Open Strong GPS Maintain Line Areas Signal of Sight Fly Below 400 Feet (120 m) Avoid flying over or near obstacles, crowds, high voltage power lines, trees or bodies of water.
Stay away from the rotating propellers No Fly Zone Learn more at: and motors. http://flysafe.dji.com/no-fly It’s important to understand basic flight guidelines, for the safety of both you and those around you. Don't forget to read the Disclaimer and Safety Guidelines. MAVIC is a trademark of DJI. Copyright © 2018 DJI All Rights Reserved. Designed by DJI. Printed in China.
