Aircraft
Phantom 3 Standard User Manual
Using the Battery
LED1
LED2
Battery Level Indicators
LED3
LED4
Power Button (Built-in LED)
urning On or Turning Off the Battery
Press the power button once, again, and hold for 2 seconds.
When turning off the battery, the power button may continue to ash for a few seconds if the
aircraft is still storing media les to the Micro SD card.
DJI Intelligent Flight Battery Functions
1.
Battery Level Display:
LEDs display the current battery level.
2.
Battery Life Display:
LEDs display the current battery life.
3.
Auto-Discharging Function:
The battery automatically discharges to below 65% of battery level when
it is left idle (pressing the power button will exit idle state) for more than 10 days to prevent swelling.
It takes about two days to discharge the battery from 100% to 65%, and it is normal to feel moderate
heat emitting from the battery during the discharge process. The discharge thresholds can be
adjusted in the DJI GO app.
4.
Balanced Charging:
Automatically balances the voltage of each battery cell when charging.
5.
Overcharge Protection:
Automatically stops charging the battery when it is fully charged.
6.
Temperature Detection:
The battery will only charge when its core temperature is between 0°C and
40°C (32°F and 104°F).
7.
Overcurrent Protection:
The battery stops charging when the maximum current of 8A is exceeded.
8.
Over-Discharge Protection:
The battery stops discharging when the battery voltage reaches 12V to
prevent damage from over-discharge.
9.
Short Circuit Protection:
Automatically cuts the power supply when a short circuit is detected.
10.
Battery Cell Damage Detection:
The DJI GO app display a warning message if a damaged battery
cell is detected.
11.
Battery Log:
Show the last 32 entries of battery information including warning messages.
12.
Sleep Mode:
The battery enters sleep mode after 20 minutes of inactivity to save power.
13.
Communication:
The battery voltage, capacity, current and other relevant information is sent to the
ight controller.
Read the Phantom 3 Standard Intelligent Flight Battery Safety Guidelines before use. Users take
full responsibility for all operations and usage.
