User manual

Aircraft

Phantom 3 Standard

User Manual

ChargerIntelligent Flight Battery

Power Outlet

Charging the Intelligent Flight Battery

1. Connect the battery charger to a suitable power supply (100-240V, 50/60Hz).

2. Open the protection cap on the battery charger and connect it to the Intelligent Flight Battery. If the

battery level is above 95%, turn on the battery before charging, otherwise it will not be fully charged.

3. The Battery Level Indicator will display the current battery level as it is charging.

4. The Battery Level Indicators will turn off when charging is complete. Disconnect the Intelligent Flight

Battery from the battery charger.

Always turn off the Intelligent Flight Battery before inserting it into or removing it from the aircraft.

Air cool the Intelligent Flight Battery after each flight. Allow its temperature to drop to room

temperature before charging it.

LED Patterns

LED1 LED2 LED3 LED4 Battery Life

90%~100%

80%~90%

70%~80%

60%~70%

50%~60%

40%~50%

30%~40%

20%~30%

Below 20%

When the battery life reaches 0%, the Intelligent Flight Battery must be replaced.

For more information about the battery, launch the DJI GO app and tap in Camera

View.

CheckingtheBatteryLife

The battery life indicates the number of cycles the battery can be charged and discharged before it must

be replaced. When the battery is turned off, press and hold the power button for 5 seconds to check the

battery life. The Battery Level Indicator will light up with one of the following LED patterns:
