User Manual

Battery Level Indicators while Charging

LED1 LED2 LED3 LED4 Battery Level

0%~25%

25%~50%

50%~75%

75%~100%

Fully Charged

Battery Protection Mechanism

The table below shows the LED blinking patterns and their corresponding battery protection warning.

Battery Level Indicators while Charging

LED1 LED2 LED3 LED4 BlinkingPattern Battery Protection Warning

LED2 blinks twice per second Over current detected

LED2 blinks three times per second Short circuit detected

LED3 blinks twice per second Overcharge detected

LED3 blinks three times per second Charger overvoltage detected

LED4 blinks twice per second

Charging temperature is too low

(<0°C)

LED4 blinks three times per second

Charging temperature is too high

(>40°C)

After any of the above protection issues are resolved, press the power button to turn off the battery

protection warning. Unplug the Intelligent Flight Battery from the battery charger and plug it back in to

resume charging. Note that you do not need to unplug and plug the battery charger in the event of a

room temperature error; the battery charger will resume charging when the temperature falls within the

normal range.

DJI does not take any responsibility for damage caused by third-party battery chargers.

Discharging the Intelligent Flight Battery

Slow :

Place the Intelligent Flight Battery into the Phantom 3 Standard’s battery compartment and

turn it on. Leave it on until there is less than 8% of battery remaining, or until the battery can no

longer be turned on. Check the battery level in the DJI GO app.

Fast :

Fly the Phantom 3 Standard outdoors until there is less than 8% of battery remaining or

until the battery can no longer be turned on.
