User manual

Remote Controller

Phantom 3 Standard

User Manual

Remote Controller Operation

The remote controller is set to Mode 2 by default.

Neutral Position: The control stick is released and in the central position.

Remote Controller

Aircraft

(

Indicates nose direction)

Operation

Vertical movement of the left stick controls the

aircraft’s elevation. Push up to ascend and

press down to descend.

Use the left stick to take off when the motors

are spinning at idle speed. The aircraft will

hover in place if the stick is in the neutral

position.

Horizontal movement of the left stick controls

the aircraft's heading. Move left to rotate the

aircraft counter clock-wise and move right to

rotate the aircraft clockwise.

Vertical movement of the right stick controls

the aircraft’s pitch. Push up to y forwards

and press down to y backwards.

Move the stick further for a larger pitch angle

and faster ight.

Horizontal movement of the right stick controls

the aircraft’s roll. Move the stick left to y left

and right to y right.

Move the stick further for a larger roll angle

and faster ight.

Turn the Gimbal Dial to the right to tilt the camera

upwards, and to the left to tilt the camera

downwards.
