User manual

Remote Controller

Phantom 3 Standard User Manual

Battery Level Indicator

The gure below illustrates the four battery levels that are displayed by the Battery Level Indicator on the

remote controller's front panel.

Always ensure the remote controller has an adequate battery level before each ight. If the battery

level is critically low, the remote controller will sound an alert and its Status LED will blink red for

3 seconds before automatically powering off. If the remote controller powers off during ight, the

aircraft will enter Failsafe RTH.

Position 1 Position 2 Position 3

Toggle the S1 switch back and forth multiple

times to regain the control of the aircraft during

Failsafe RTH.

Toggle the S1 switch back and forth for more

than 3 times to calibrate the aircraft's compass.

Toggle the S1 switch to position 1 to enable

P-Mode, to position 2 to enable A-Mode, and to

position 3 to enable F-Mode.

Position 1 Position 2 Position 3

Toggle the S2 switch back and forth at least

twice to initiate Smart RTH. Use the S2 switch

and the gimbal dial to link with the aircraft and

reset the WiFi password. Refer to Linking the

Remote Controller on page 24 and Resetting

the WiFi Video Downlink on page 26 for more

details.

The aircraft will hover in place when both sticks are released and GPS is available.

If GPS is not available, the aircraft will lock its altitude but drift from side to side.

Battery Level Indicator

25％ 50％ 75％ 100％

Optimal Transmission Range

To achieve optimal transmission, point the top of the remote controller at the aircraft, and adjust the

antenna so that it is parallel to the aircraft’s legs (or simply tilt it at a 45 degree angle).

Optimal Transmission Range
