Remote Controller
Phantom 3 Standard User Manual
The CE compliant remote controller has an effective signal range of 0.31 miles (500 m) in open
spaces.
The FCC compliant remote controller has an effective signal range of 0.62 miles (1000 m) in open
spaces.
Be aware of your ying distance as the aircraft will enter Failsafe RTH if it ies beyond
transmission range.
Remote Controller Status LED Description
Status LED Sound Remote Controller Status
— Solid green None Functioning normally and fully charged.
— Solid red None
Charging (remote controller is powered off).
Remote controller is not connected to the aircraft.
— Solid yellow None
Control stick calibration error. Battery fully charged but
remote controller is not connected to the aircraft.
Blinks red slowly BB---BB---BB Low battery level. Recharge the remote controller.
Blinks red quickly B-B-B...
Critically low battery level, the remote controller will
automatically power off after 3 seconds / The remote
controller is switched on with the control stick not in the
neutral position.
Blinks green slowly B--B--B...
Inactivity for over 6 minutes. Switch off the remote con-
troller if it is not in use.
WiFi Video Downlink
Used to boost the transmission range between the on-board camera and the remote controller, the 2.4
GHz WiFi video downlink is integrated into the remote controller and provides the device with an effective
communication range of up to 0.62 miles (1000 m). It also enables the remote controller to connect to the
DJI GO app wirelessly.
ConnectingtotheWiFiVideoDownlink:
1. Switch on the remote controller.
2. Turn on the aircraft.
3. On your mobile device, select 'PHANTOM3_XXXXXX' from the WiFi network list, and enter the default
password '12341234'.
4. Launch the DJI GO app and enter Camera View. A video signal from the aircraft's camera indicates
that the aircraft has established a connection to the WiFi video downlink successfully.
