Gimbal Camera
Phantom 3 Standard User Manual
Anti-Drop Kit
The Phantom 3 Standards comes with two Anti-Drop Pins which help secure the gimbal and camera to
the aircraft. To install additional pins, follow these steps:
Push the Anti-Drop Pin through the damper and the center of the ring. Press them together until you hear
a click. Only 2 pins installed adjacent from each other are required during use.
Follow Mode The pitch angles of the gimbal and the aircraft stay the same.
FPV Mode
The pitch and roll angles of the gimbal and the aircraft stay the same,
providing a unique rst-person view.
Take off from a at, open ground that will not interfere with the gimbal movement.
A gimbal motor error may occur in these situations:
(1) The gimbal’s motion is obstructed by the gimbal clamp or obstacles on the ground.
(2) The gimbal was subjected to an excessive external force such as a collision.
Flying in heavy fog or clouds may make the gimbal wet, leading to a temporary failure. The
gimbal will recover full functionality once it dries.
Gimbal Operation Modes
Two gimbal operation modes are available. Switch between the different operation modes on the
camera settings page of the DJI GO app. Note that your mobile device must be connected to the remote
controller for changes to take effect. Refer to the table below for details:
Anti-Drop Pin
'click'
Ring
