User manual

38
©
2015 DJI. All Rights Reserved.
Flight
Phantom 3 Standard User Manual
WeakGPSSignal Flashing Yellow
Flight Limits DJI GO App Aircraft Status Indicator
Max Height
Flight height restricted to
Max Height under 400 ft
(120 m).
Warning: Height limit
reached.
None.
Max Radius No limit
If you y out of bounds, you can still control the aircraft, but cannot y it further.
If the aircraft loses GPS signal and ies out of the max radius but regains GPS signal afterwards,
it will y back within range automatically.
No Fly Zones
All No Fly Zones are listed on the DJI ofcial website at http://ysafe.dji.com/no-y. No Fly Zones are
divided into Airports and Restricted Areas. Airports include major airports and ying elds where
manned aircraft operate at low altitudes. Restricted Areas include borders between countries or
sensitive sites. The details of the No Fly Zones are explained below
.
Airports (Requires GPS):
1. Airport No Fly Zones are comprised of Takeoff Restricted Zones and Restricted-Altitude Zones. Each
type of zone encompasses a radius of a certain size.
2. The radius R1 depends on the shape and size of the airport, and is an area around the airport that is a
Takeoff Restricted Zone, inside of which takeoff and ight is inhibited.
3. From R1 to R1+1 miles around the airport, the ight altitude is limited on a 15 degree incline, starting at
66 feet (20 m) from the edge of airport and radiating outwards. The ight altitude is limited to 1640 feet
(500 m) at R1+1 miles.
4. When the aircraft is within 320 feet (100 m) of a no-y zone, a warning message will appear in the DJI
GO app.
Strong GPS Signal Flashing Green
Flight Limits DJI GO App Aircraft Status Indicator
Max Height
Flight altitude must be below the
preset height.
Warning: Height
limit reached.
None.
Max Radius
Flight distance must be within
the max radius.
Warning: Distance
limit reached.
Flashes red rapidly
when the aircraft
approaches the max
radius limit.
