Appendix
Phantom 3 Standard User Manual
Remote Controller
Operating Frequency 5.725 GHz - 5.825 GHz
,
922.7 MHz - 927.7 MHz
（
Japan
）
Max Transmission Distance
FCC: 1000 m
;
CE: 500 m
(outdoors and unobstructed, aircraft’s altitude at 400 feet/120 m)
Operating Temperature 0° to 40° C
Battery 2600 mAh LiPo 18650
Transmitter Power (EIRP) FCC: 19 dBm
；
CE: 14 dBm
Operating Voltage 600 mA @ 3.7V
Charging Port Micro USB
Battery Charger
Output Voltage 17.4 V
Rated Power
57 W
Intelligent Flight Battery (PH3 - 4480 mAh - 15.2 V)
Capacity 4480 mAh
Voltage 15.2 V
Battery Type LiPo 4S
Energy 68 Wh
Net Weight 365 g
Operating Temperature -10° to - 40° C
Max Charging Power 100 W
Aircraft Status Indicator Blinking Patterns
Normal Operations
Flashes red, green and yellow alternatively Powered on and self-testing
Flashes green and yellow alternatively Aircraft warming up
Flashes green slowly Safe to Fly (P-Mode with strong GPS signal)
Flashes yellow slowly Safe to Fly (A-Mode without GPS signal)
Warnings
Flashes yellow quickly Remote controller signal lost
Flashes red slowly Low Battery Warning
Flashes red quickly Critically Low Battery Warning
Flashes red
(Alternates with other patterns)
IMU eror
— Glows solid red Critical error
Flashes red and yellow alternatively Compass calibration required
