User Manual

©
2017 DJI All Rights Reserved.
23
Spark User Manual
Feature Descriptions Front LEDs Figure
PalmLaunch
1. Power on the aircraft while holding it. Wait for
the aircraft status indicators to blink yellow.
Make sure your fingers are well below the
aircraft arms.
——
Solid red
2. Next, tap the Intelligent Flight Battery power
button twice. The front LEDs should blink yellow
slowly.
Blinks yellow
3. FaceAware will start to work automatically.
When FaceAware activates successfully,
the aircraft beeps twice and the front LEDs
become solid green. If the front LEDs blink
red twice, then FaceAware has failed. Please
repeat step 2.
——
Solid green
4. The front LEDs will glow solid red after the
motors start spinning. Release the aircraft and it
will hover in place.
——
Solid red
Start PalmControl
1. Stand in front of the aircraft, then raise and
extend one of your arms in the direction of
the aircraft. Extend your fingers and keep
them close together. Position your palm
about 0.7 m in front of the aircraft's nose for
about two seconds.
——
Solid green
0.7 m
2. The front LEDs will glow solid green if the
PalmControl activation is successful. Adjust
your distance from the aircraft if the front LEDs
start to blink yellow fast. This means you are too
close or too far away from the aircraft.
Adjusting Position
1. Move your palm up or down slowly to control
the aircraft’s altitude while maintaining a
constant distance between your palm and the
aircraft.
——
Solid green
0.7 m
2. Keep your palm at a constant distance from
your body (as shown), then move your arm left
or right to control the aircraft’s orientation.
3. Keep your palm at a constant distance from
your body, move forward or backward to y
forward or backward.
