Specifications

G0
65VN01 V2 Ver. 1.2
12/24
G
065VN01 V2
5.2 Backlight Unit Driving
5.2.1 Parameter guideline for LED driver
Following characteristics are measured under stable condition at 25 om Temperature).
Symbol Parameter Min Typ Max Units
Remark
V
LED
Input Voltage 9 12 13 Volt
I
LED
Input Current - 0.25 A 100% PWM duty
P
LED
Power Consumption - 3.0 W 100% PWM duty
Irush
LED
Inrush Current - 0.37 0.41 A 100% PWM duty
On Control Voltage 3.0 3.3 5.0 Volt
V
LED On/Off
Off Control Voltage 0 0.15 Volt
Dimming control Voltage High 3.0 3.3 5.0 Volt
V
PWM
Dimming control Voltage Low 0 0.1 Volt
F
PWM
Dimming Frequency 200 30K Hz
D
PWM
Dimming duty cycle 1 100 %
Operating Life
50000
Hrs Note 2, 3
Note 1: See Section 6.6 for LED Backlight Unit Interface Signal Description.
Note 2: If G065VN01 V2 module is driven at high ambient temperature & humidity condition. The operating life will be
reduced.
Note 3: Operating life means brightness goes down to 50% initial brightness. Typical operating life time is estimated data.
