6.5 TFT- LCD Interface Timing
6.5.1 Timing Characteristics
DE mode only
Signal Symbol
Min. Typ. Max. Unit Remark
Clock frequency (DOTCLK) 1/ T
CLOCK
20 25.2 50 MHz Note1
Period T
H
770 800 1070
Active T
HD
640
Horizontal Section
Blanking T
HB
130 160 430
T
CLOCK
Note1
Period T
V
520 525 622
Active T
VD
480
Vertical Section
Blanking T
VB
40 45 142
T
LINE
Note1
Note 1: Recommended frame rate is 60 Hz.
6.5.2 Input Timing Diagram
DOTCLK
DE
T
H
T
HB
T
HD
DE
T
V
T
VB
T
VD
Input Timing Definition ( DE Mode)
T
CLOCK
Input
Data
Pixel
1
Pixel
2
Pixel
3
Pixel
N-1
Pixel
N
Invaild
Data
Invaild
Data
Pixel
1
