6.6 LED Backlight Unit Interface Signal Description
Pin # Symbol Pin Description
1 V
LED
12V input
2 V
LED
12V input
3 GND Ground
4 GND Ground
5 LED On/Off 3.3V-On; 0V/NC-Off
6 PWM DIM 1~100%
Note1: “NC stands for “No Connection””.
