Specifications

155 ±0,3 ODT
117 ±0,3 ODT
0,90 ±0,5
139 VAT
104 VAT
133 AAT
100 AAT
80 ±1
132,48 AAD
99,36 AAD
Contact
12,43 (max. 12,93)
118 ±0,5 ODD
153 ±0,5 ODD
1,90 ±0,5
1
3
2
M 1:2
Pos. Quantity File Number Description
1 1 1009880-T TFT-LCD MODULE 6,5"
2 1 1009864-T Touch
3 1 1009940-T Klebeband 3x0,13
ODD Outline Dimension Display
ODT Outline Dimension Touch
VAT Viewing Area Touch
AAT Active Area Touch
AAD Active Area Display
CONRAC GMBH / Data Modul AG
REL.DATE
SCALE
FINISH
MATERIAL
REV.
FILE NUMBER:
DRAWING TITLE
DRAWN BY
E.C.-NO.
DRAWING/PART NUMBER
RELEASED:
PROJECT:
TOLERANCES DIN ISO 2768-mK
SURFACES DIN ISO 1302
MODIFICATION/DESCRIPTION
SIZE ISO
A3
000
26.02.2013
Aschenbrenner
Neuanlage
ja
DMO_C_
2:3
Assembly
TFT Display 6,5" + resistive Touch
12002651
1009941
000
10000
NO. OF
CHANGES
D-97990 Weikersheim D-80687 München
B
A
8 7 6 4
D
C
5 1 2 3
A
B
4 3 2 1
C
F
E
D
NOT TO BE DISCLOSED TO THIRD PARTY WITHOUT PERMISSION FROM
This drawing is only schematic representation of the structure.
The parts to be used are defined in the ProAlpha parts list.
