Specifications

G0
65VN01 V2 Ver. 1.2
3/24
G
065VN01 V2
Record of Revision
Version and Date
Page
Old description New Description Remark
0.1, Apr. 23, 2009
All First edition preliminary specifications
5
Temperature Range
Operating: -30 to +85
Storage (Non-Operating): -30 to +85
Temperature Range
Operating: -30 to +80*
Storage (Non-Operating): -30 to +80*
*:Panel surface temperature
Section 2.1
6
White Luminance:
Min: 500, Typ: 700
White Luminance:
Min: 600, Typ: 800
Section 2.2
6
Color / Chromaticity
Coordinates
Red x, Red y: TBD
G
reen x, Green y: TBD
Blue x, Blue y: TBD
C
olor / Chromaticity
Coordinates
Section 2.2
6
Color Gamut
Min: TBD
Color Gamut
Min: 50%
Section 2.2
9
Absolute Ratings of Environment
Operating Temperature, Max: +85
Storage Temperature, Max: +85
Absolute Ratings of Environment
Operating Temperature, Max: +80*
Storage Temperature, Max: +80*
*: Panel surface temperature
Section 4.2
12
IrushLED
Typ/Max: TBD
IrushLED
Typ: 0.37 A, Max: 0.41 A
Section 5.2.1
12
Operating Life
Min: 25000, Max: 50000
Operating Life
Min: 50000
Section 5.2.1
17
LED Backlight Unit Interface Signal
Description
Pin 5 LED On/Off: 3.3V-On; 0V-Off
LED Backlight Unit Interface Signal
Description
Pin 5 LED On/Off: 3.3V-On; 0V/NC-Off
Section 6.6
1.0, Oct. 22, 2009
21
Reliability Test Criteria
High Temperature Operation:
300Hr
High Temperature Storage:
300Hr
Thermal Shock Test:
-2
,
Hot Start Test:
85℃
/1 Hr (min.), power on/off per 5 minutes,
repeat 5 times
Reliability Test Criteria
High Temperature Operation:
8
0
*, 300Hr
High Temperature Storage:
80
*, 300Hr
Thermal Shock Test:
-3
, 8 min ,100cycles
Hot Start Test:
80℃*/1 Hr (min.), power on/off per 5
minutes, repeat 5 times
*: Panel surface temperature
Section 8
1.1, Mar. 22, 2012
12
V
LED On/Off
and
V
PWM
range
V
LED On/Off
and V
PWM
range
Section 5.2.1
1.2, May 21, 2012
20
Section 7.3
9
LED BLU Drive Absolute Ratings Voltage
range
LED BLU Drive Absolute Ratings
Voltage range
Section 4.1
1.3, July 03, 2012
12
V
LED
i
nput voltage range
V
LED
i
nput voltage range
Section 5.2.1
