2. General Description
G
065VN01 V2 is designed for industrial display applications with VGA (640 x RGB x 480) resolution
and 16.2M (RGB 6-bits + FRC) or 262k colors (RGB 6-bits). It is composed of a TFT-LCD panel,
driver ICs, control and power supply circuits board and a backlight unit including LED driving circuit.
G065VN01 V2 offers LVDS interface for display signal input.
2.1 Display Characteristics
The following items are G065VN01 V2 characteristics
summary at 25 (Room Temperature).
Items Unit Specifications
Screen Diagonal inch 6.5
Active Area mm 132.48(H) x 99.36(V)
Pixels H x V 640x3(RGB) x 480
Pixel Pitch mm 0.207 x 0.207
Pixel Arrangement R.G.B. Vertical Stripe
Display Mode TN, Normally White
Nominal Input Voltage VDD Volt 3.3 typ.
Typical Power Consumption Watt
3.86W (LCD:0.86W/LED BLU: 3.0W)
All black pattern
Weight Grams 170g (typ.)
Physical Size mm 153.0(H)x 118.0(V) x 10.9(D) (typ.)
Electrical Interface 1 channel LVDS
Surface Treatment Glare, AR, Hardness: 3H
Support Color 16.2M / 262K colors
The most suitable view angle 6 o’clock
Temperature Range
Operating
Storage (Non-Operating)
o
C
o
C
-30 to +80*
-30 to +80*
*Panel surface temperature
RoHS Compliance RoHS Compliance
