Specifications

G0
65VN01 V2 Ver. 1.2
6/24
G
065VN01 V2
2.2 Optical Characteristics
The optical characteristics are measured under stable con
ditions at 25 (Room Temperature).
Item Unit Conditions Min. Typ. Max. Remark
White Luminance cd/m2
F
PWM
= 100%
(center point)
600 800 - Note 1
Uniformity
%
5 Points
- 1.25
Note
1, 2, 3
Contrast Ratio
400 600 - Note 4
msec Rising
-
15 20
msec Falling
- 10 15
Response Time
msec Rising + Falling
- 25 35
Note 5
degree
degree
Horizontal (Right)
CR = 10 (Left)
70
70
80
80
-
-
Viewing Angle
degree
degree
Vertical (Upper)
CR = 10 (Lower)
60
60
70
70
-
-
Note 6
White x
0.263 0.313 0.363
White y
0.279 0.329 0.379
Red x
0.559 0.609 0.659
Red y
0.314 0.364 0.414
Green x
0.285 0.335 0.385
Green y
0.554 0.604 0.654
Blue x
0.099 0.149 0.159
Color / Chromaticity
Coordinates
(CIE 1931)
Blue y
0
.055 0.105 0.155
Color Gamut % 50 55 -
Note 1: Measurement method
Equipment Pattern Generator, Power Supply, Digital Voltmeter, Luminance meter (SR_3 or equivalent)
Aperture
Test Point Center
Environment < 1 lux
LCD Module
SR_3 or
equivalent
measuring distance
Module Driving Equipment
