Specifications

G0
65VN01 V2 Ver. 1.2
7/24
G
065VN01 V2
Note 2: Definition of 5 points position (Display active area: 132.48mm(W) x 99.36mm(H))
1 2
3
4 5
H / 4
H / 4
H /4
H /4
H
W
W / 4 W / 4 W / 4 W /4
Note 3:
The luminance uniformity of 5 points is defined by dividing the maximum luminance value by the minimum luminance value
at full white condition.
Note 4: Definition of contrast ratio (CR):
N
ote 5: Definition of response time:
The output signals of photo detector are measured when the input signals are changed from “White” to “Black” (falling time)
and from “Black” to “White” (rising time), respectively. The response time interval definition is between 10% and 90% of
amplitude. Please refer to the figure as below.
Maximum
Brightness of five points
δ
W5
=
M
inimum
Brightness of five points
Contrast ratio (CR)
=
Brightness @ “White” state
Brightness @ “Black” state
100
90
10
0
%
Optical
respon se
White
Black
White
Tf
Tr
90
10
0
Optical
respon se
White
Black
White
Tr
