Instruction Manual

A-121
VCF 2
System A - 100
doepfer
2
2. VCF 2 - Overview
Controls:
1 Audio Level : Input signal attenuator
2 Freq. : Cut-off frequency control
3 FCV 2 : Attenuator for filter CV §
4 Res. : Resonance control
5 QCV 2 : Attenuator for resonance CV %
In / Outputs:
! Audio In : Audio input to the filter
" FCV 1 : Cut-off frequency CV input
§ FCV 2 : ditto, level controlled by 3
$ QCV 1 : Resonance CV input
% QCV 2 : ditto, level controlled by 5
& Low : Low-pass filter output
/ Band : Band-pass filter output
( High : High-pass filter output
) Notch : Notch filter output
VCF 2
FCV 1
FCV 2
QCV 1
Freq.
FCV 2
Res.
QCV 2
Audio In
➊
➏
➐
➑
➒
➀
➁
➂
➃
➄
QCV 2
0
10
0
10
0
10
0
10
MULTIMODE FILTER
0
10
Audio
Level
Low
Band
High
Notch
➋
➌
➍
➎
