CFX3_OPM_APAC(en).book Seite 1 Mittwoch, 24.
CFX3_OPM_APAC(en).book Seite 2 Mittwoch, 24. Juni 2020 11:07 11 © 2020 Dometic Group. The visual appearance of the contents of this manual is protected by copyright and design law. The underlying technical design and the products contained herein may be protected by design, patent or be patent pending. The trademarks mentioned in this manual belong to Dometic Sweden AB. All rights are reserved.
CFX3_OPM_APAC(en).book Seite 3 Mittwoch, 24.
CFX3_OPM_APAC(en).book Seite 4 Mittwoch, 24. Juni 2020 11:07 11 CFX3 3 1 2 3 4 DC V 11.8 -8 °C CFX3 35, CFX3 45, CFX3 55 CFX3 55 IM CFX3 75DZ, CFX3 95DZ DC V DC V DC V 11.8 11.8 11.
CFX3_OPM_APAC(en).book Seite 5 Mittwoch, 24. Juni 2020 11:07 11 CFX3 5 2. 1. 3. 180° 4. 3. 1. 2.
CFX3_OPM_APAC(en).book Seite 6 Mittwoch, 24. Juni 2020 11:07 11 CFX3 6 2. 1. 3. 1. 1. 2. 2. 180° 1. 2. 2. 6 1. 3.
CFX3_OPM_APAC(en).book Seite 7 Mittwoch, 24. Juni 2020 11:07 11 CFX3 7 1. 2. 8 1. 3. 100 – 240 Vw 2.
CFX3_OPM_APAC(en).book Seite 8 Mittwoch, 24. Juni 2020 11:07 11 CFX3 9 2. 3. DC V 11.8 ° CLICK 1. 0 1. 2. 12/24 V 100 – 240 V 1. 3 sec 2. 1. a A B DC V DC V 11.7 11.7 -8 °C 8 C -8 °C 2.
CFX3_OPM_APAC(en).book Seite 9 Mittwoch, 24. Juni 2020 11:07 11 CFX3 b CFX3 35/CFX3 45/ CFX3 55 CFX3 55IM DC V DC V DC V 11.8 11.8 11.8 -8 °C -8 °C CFX3 75DZ/ CFX3 95DZ 8 °C -12 °C Set temp Set temp Set temp Battery protection Battery protection Battery protection Bluetooth Bluetooth Bluetooth WiFi WiFi WiFi Display Display Display Temp units Temp units Temp units Ice maker Zone control c 3 sec DC V DC V 11.8 11.
CFX3_OPM_APAC(en).book Seite 10 Mittwoch, 24. Juni 2020 11:07 11 CFX3 e CFX3 35/CFX3 45/CFX3 55/CFX3 55IM DC V Set temp Set temp Set temp 11.8 Battery protection -8 -8 °C °C -8 °C Bluetooth -6 °C WiFi Set temp -6 °C CFX3 75DZ/CFX3 95DZ Set temp 6 °C -12 °C Set temp 6 °C -12 °C Set temp 8 °C -12 °C Set temp DC V Set temp Set temp 11.
CFX3_OPM_APAC(en).book Seite 11 Mittwoch, 24. Juni 2020 11:07 11 CFX3 f DC V Set temp Battery protection Battery protection 11.8 Battery protection -8 °C Bluetooth WiFi Low High High Medium Medium Low Low ... Medium/High 12 V 24 V Low Medium High 10.1 V 11.2 V 11.8 V 11.4 V 12.2 V 12.6 V 21.5 V 24.1 V 24.6 V 23.0 V 25.3 V 26.2 V g ... Display Display DC V Display 11.8 Temp units -8 °C Display ...
CFX3_OPM_APAC(en).book Seite 12 Mittwoch, 24. Juni 2020 11:07 11 CFX3 h CFX3 75DZ/CFX3 95DZ DC V Display Zone control Zone control Both On Both On Large On Large On Small On Small On Ice maker Ice maker 11.8 Temp units 8 °C -12 °C Zone control i CFX3 55 IM Display DC V 11.8 -8 °C 12 Temp units On On Ice maker Off Off ...
CFX3_OPM_APAC(en).book Seite 13 Mittwoch, 24. Juni 2020 11:07 11 CFX3 j 1 2 k DC V Set temp Bluetooth Bluetooth 11.8 -8 °C Battery protection ON ON Bluetooth OFF OFF WiFi PAIR PAIR Bluetooth DC V 11.
CFX3_OPM_APAC(en).book Seite 14 Mittwoch, 24. Juni 2020 11:07 11 CFX3 l DC V Set temp WiFi WiFi 11.8 -8 °C Battery protection ON ON Bluetooth OFF OFF RESET RESET WiFi WiFi WiFi WiFi ON Are you sure want to reset? OFF RESET No Yes WiFi Are you sure want to reset? No Yes m 3 sec DC V 11.8 + + FACTORY -8 °C n RESET A DC V 11.7 11.
CFX3_OPM_APAC(en).book Seite 15 Mittwoch, 24. Juni 2020 11:07 11 CFX3 o 1. 2 A/5 V 2. p 1. 2. 3. 4.
CFX3_OPM_APAC(en).book Seite 16 Mittwoch, 24. Juni 2020 11:07 11 CFX3 Please read this manual carefully before starting the device. Keep it in a safe place for future reference. If the device is passed on to another person, this manual must be handed over to the user along with it. The manufacturer cannot be held liable for damage resulting from improper usage or incorrect operation. Contents 1 Explanation of symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CFX3_OPM_APAC(en).book Seite 17 Mittwoch, 24. Juni 2020 11:07 11 CFX3 Explanation of symbols 7.19 7.20 7.21 7.22 7.23 7.24 7.25 Resetting to factory settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31 USB port for power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31 Defrosting the cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31 Replacing the AC fuse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CFX3_OPM_APAC(en).book Seite 18 Mittwoch, 24. Juni 2020 11:07 11 Safety instructions CFX3 2 Safety instructions ! WARNING! Failure to obey these warnings could result in death or serious injury. Electrocution hazard • Do not operate the cooling device if it is visibly damaged. • If this cooling device's power cable is damaged, it must be replaced by the manufacturer, customer service or a similarly qualified person in order to prevent safety hazards.
CFX3_OPM_APAC(en).book Seite 19 Mittwoch, 24. Juni 2020 11:07 11 CFX3 Safety instructions • Disconnect the cooling device from the power supply – before each cleaning and maintenance – after every use Health hazard • Please check if the cooling capacity of the device is suitable for storing the food or medicine you wish to cool. • Food may only be stored in its original packaging or in suitable containers.
CFX3_OPM_APAC(en).book Seite 20 Mittwoch, 24. Juni 2020 11:07 11 Scope of delivery CFX3 • Do not use electrical devices inside the cooling device unless they are recommended by the manufacturer for the purpose. • Do not place the cooling device near naked flames or other heat sources (heaters, direct sunlight, gas ovens etc.). • Risk of overheating! Ensure at all times that there is a minimum of 50 mm ventilation on all four sides of the cooling device.
CFX3_OPM_APAC(en).book Seite 21 Mittwoch, 24. Juni 2020 11:07 11 CFX3 Intended use Designation Ref. no. Model Protective cover 9600026468 CFX3 35 9600026469 CFX3 45 9600026470 CFX3 55 CFX3 55IM Fridge slide 9600026471 CFX3 75DZ 9600026472 CFX3 95DZ 9610000651 CFX3 35 CFX3 45 9610000652 CFX3 55 CFX3 55IM CFX3 app 9105306633 CFX3 75DZ 9105306558 CFX3 95DZ – suits all models Note that the CFX3 app may not be available in your country.
CFX3_OPM_APAC(en).book Seite 22 Mittwoch, 24. Juni 2020 11:07 11 Function description 6 CFX3 Function description The cooler can chill products, keep them cool as well as freeze them. A low maintenance refrigerant circuit with compressor provides the cooling. The generous insulation and powerful compressor ensure efficient and fast cooling. The cooler is portable. The cooler can withstand a short-term inclination of 30°. 6.
CFX3_OPM_APAC(en).book Seite 23 Mittwoch, 24. Juni 2020 11:07 11 CFX3 6.2 Function description Operating and display elements Latch for lid: fig. 2 1, page 3 Operating panel (fig.
CFX3_OPM_APAC(en).book Seite 24 Mittwoch, 24. Juni 2020 11:07 11 Operation CFX3 7 Operation 7.1 Before initial use I 7.2 NOTE Before starting your new cooler for the first time, you should clean it inside and outside with a damp cloth for hygienic reasons (please also refer to the chapter “Cleaning and maintenance” on page 33). Energy saving tips • Choose a well ventilated location which is protected from direct sunlight.
CFX3_OPM_APAC(en).book Seite 25 Mittwoch, 24. Juni 2020 11:07 11 CFX3 Operation Connecting to a battery ➤ Proceed as shown (fig. 7, page 7). Connecting to an AC power supply D DANGER! Electrocution hazard • Never handle plugs and switches with wet hands or if you are standing on a wet surface. • If you are operating your cooler on board a boat from a AC power supply, you must install a residual current circuit breaker between the AC power supply and the cooler. Seek advice from a trained technician.
CFX3_OPM_APAC(en).book Seite 26 Mittwoch, 24. Juni 2020 11:07 11 Operation CFX3 Display overview: fig. b, page 9 Navigating through the menus The highlighted menu is selected. ➤ Press to navigate upwards. ➤ Press to navigate downwards. Choosing a menu ➤ Press to select the required menu. Changing settings The highlighted value or setting is selected. ➤ Press to increase the selected value or to choose the previous setting. ➤ Press to decrease the selected value or to choose the next setting.
CFX3_OPM_APAC(en).book Seite 27 Mittwoch, 24. Juni 2020 11:07 11 CFX3 7.10 Operation Using the battery protection The device is equipped with 3-stage battery protection. The battery protection prevents excessive discharging when the device is connected to a vehicle starter battery or maximises the use of a supply battery. If the cooler is operated when the vehicle ignition is switched off, the cooler switches off automatically as soon as the supply voltage falls below a set level.
CFX3_OPM_APAC(en).book Seite 28 Mittwoch, 24. Juni 2020 11:07 11 Operation CFX3 7.13 Using the ice maker (only CFX3 55IM) I NOTE • Independent of the main compartment‘s temperature setting, the ice maker zone is designed for making ice cubes if the ice maker is switched on. • The cooler‘s energy consumption increases with ice maker on. Therefore you should switch off the ice maker if it is not needed. • The factory setting for the ice maker is OFF. ➤ Proceed as shown (fig. i, page 12).
CFX3_OPM_APAC(en).book Seite 29 Mittwoch, 24. Juni 2020 11:07 11 CFX3 Operation Removing the ice maker housing The ice maker housing can be removed for cleaning or when not in use to increase usable space inside the cooler: ➤ Lift the housing at one end until the lug unclips, then remove. ➤ Reverse procedure for re-fit, pushing down on lugs to snap into position.
CFX3_OPM_APAC(en).book Seite 30 Mittwoch, 24. Juni 2020 11:07 11 Operation 7.15 CFX3 Setting the Bluetooth signal and connecting to the app The cooler can be monitored and controlled via Bluetooth. To do so, you have to pair the cooler with your Bluetooth device. I NOTE • Pairing must be done within the CFX3 app, not in device settings. • There is no password required for Bluetooth connection. ➤ Proceed as shown (fig. k, page 13). 7.
CFX3_OPM_APAC(en).book Seite 31 Mittwoch, 24. Juni 2020 11:07 11 CFX3 7.19 Operation Resetting to factory settings The reset function changes all display menu and app fields to the original factory settings. ➤ Proceed as shown (fig. m, page 14). 7.20 USB port for power supply The USB port allows you to charge small devices like mobile phones and mp3 players. I NOTE Ensure that any small device connected to the USB port is compatible with 5 V/2 A operation. ➤ Proceed as shown (fig. o, page 15).
CFX3_OPM_APAC(en).book Seite 32 Mittwoch, 24. Juni 2020 11:07 11 Operation 7.22 D CFX3 Replacing the AC fuse DANGER! Electrocution hazard Disconnect the power supply and the connection cable before you replace the device fuse. ➤ Disconnect the power supply to the device. ➤ Pull out the connection cable. ➤ Pry out the fuse insert (fig. 4 4, page 4) with a screwdriver. ➤ Replace the defective glass fuse with a new one of the same type and rating (Fast Acting, 4 A, 250 V).
CFX3_OPM_APAC(en).book Seite 33 Mittwoch, 24. Juni 2020 11:07 11 CFX3 8 A Cleaning and maintenance Cleaning and maintenance NOTICE! Damage hazard • Never clean the cooler under running water or in dish water. • Do not use abrasive cleaning agents or hard objects during cleaning as these can damage the cooler. ➤ Occasionally clean the device interior and exterior with a damp cloth.
CFX3_OPM_APAC(en).book Seite 34 Mittwoch, 24. Juni 2020 11:07 11 Troubleshooting CFX3 Fault Possible cause Suggested remedy The display does not The display is locked. respond to keystrokes. Unlock the display, see chapter “Locking/unlocking the display” on page 26. The app cannot control the device. Bluetooth or WiFi is not connected.
CFX3_OPM_APAC(en).book Seite 35 Mittwoch, 24. Juni 2020 11:07 11 CFX3 Troubleshooting Warning codes E.g. see fig. n B, page 14. Warning code Fault Possible cause Suggested remedy !WARNING 32 Fan over-current Internal fault. !WARNING 33 Compressor start fail Turn off the device for at least 5 mins., then restart.
CFX3_OPM_APAC(en).book Seite 36 Mittwoch, 24. Juni 2020 11:07 11 Warranty 10 CFX3 Warranty If the product does not work as it should, please contact your retailer or the manufacturer's branch in your country (see dometic.com/dealer). The warranty applicable to your product is 3 years (full) plus additional 2 years compressor (parts only).
CFX3_OPM_APAC(en).book Seite 37 Mittwoch, 24. Juni 2020 11:07 11 CFX3 12 I Technical data Technical data NOTE The minimum temperature shown in „Cooling capacity“ cannot be attained if the ambient temperature is above 32 °C (90 °F) for models CFX3 35/45/55/55IM or the ambient temperature is above 30 °C (86 °F) for models CFX3 75DZ/95DZ (set small –22 °C/large +4 °C). Test/certificates: 13 CFX3 35 Connection voltage: Rated current: CFX3 55 12/24 Vg and 100 – 240 Vw 12 Vg: 7.5 A 24 Vg: 3.
CFX3_OPM_APAC(en).book Seite 38 Mittwoch, 24. Juni 2020 11:07 11 Technical data CO2 equivalent: CFX3 CFX3 35 CFX3 45 CFX3 55 0.054 t 0.060 t 0.064 t Global warming potential (GWP): Dimensions (W x D x H) in mm (including handles): Weight: 1430 398 x 694 x 407 398 x 694 x 476 720 x 455 x 480 16.9 kg 18.7 kg 20.4 kg CFX3 55IM CFX3 75DZ CFX3 95DZ Connection voltage: Rated current: 12/24 Vg and 100 – 240 Vw 12 Vg: 8.9 A 24 Vg: 3.8 A 100 Vw: 1.00 A 240 Vw: 0.
CFX3_OPM_APAC(en).book Seite 39 Mittwoch, 24. Juni 2020 11:07 11 CFX3 CO2 equivalent: Technical data CFX3 55IM CFX3 75DZ CFX3 95DZ 0.064 t 0.084 t 0.096 t Global warming potential (GWP): Dimensions (W x D x H) in mm (including handles): Weight: 1430 720 x 455 x 480 892 x 495 x 472 962 x 530 x 472 21.3 kg 27.8 kg 29.8 kg The coolant circuit contains R134a.
