miniCool EA 3100 EA 3080 RA 80 RH 200 EA 3140 RA 140 Type: MF20-60 Operating Instructions 207.5184.
Please read these operating instructions carefully before putting the refrigeration unit into operation. If you later sell or dispose of it, please ensure that the new owner receives these operating instructions. Please follow the installation details below carefully Guarantee is valid for products installed as described only. (See chapter 4.1) Thank you for choosing our appliance. We are sure it will provide you with trouble-free use.
C ONTENT S 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. 13. 14. 15. 16. Unpacking View of the appliance Cleaning Positioning the appliance 4.1. Installation instruction Using the appliance 5.1. Temperature regulation 5.2. Cooling unit control (CUC) Ice cubes Useful suggestions Defrosting, cleaning and maintenance 8.1. Automatic defrost function Changing the lightbulb Reversing the door hang Replacing the decorative door panel Assembly of door handle Customer service Putting into operation, technical data 14.1.
1. Unpacking After removal from the cardboard packaging, make sure the appliance is not damaged. If you find damage to the appliance resulting from transport, report it immediately to the transportation firm. 2. View of the appliance EA 3100 EA 3080 EA 3140 Figure 1. 1. Door lock 5. Lamp (if available) 2. Sensor 6. Fixing foot 3. Thermostat knob 7. Evaporator evaporator) 4. Evaporator sensor (behind Attention! Since Ser. No.
3. Cleaning Clean the refrigerator thoroughly at intervals, as necessary. Remove the shelves; these, the cabinet interior and the door should be washed with a warm solution of sodium bi-carbonate. Finally wipe over with a cloth rinsed in warm water only, and dry with a clean cloth. Do not wash any plastic parts in water that is more than hand warm, and do not expose them to dry heat. The outside of the cabinet should be wiped down regularly with a clean, damp cloth.
5. Only the entire cooling unit must project into the duct as shown 6. Air passing through the duct must not be preheated by any source of heat 7. Ventilation grills, if used, must have an free openings of at least 200 cm² each The refrigerator can be fixed to the bottom of the furniture through its fixing feet using screws of an appropiate length. (Fig. 4) During installation, please ensure the mains plug is accessible at all times. Figure 4. 5.
6. ICE CUBES Fill the ice tray to 4/5 with drinking water, cover with the lid and place the closed ice tray on the ice-tray shelf. Wipe off any excess water to prevent the ice tray from freezing to the surface. To speed up the making of ice cubes, turn the thermostat to position 5 for a short while. Remember to turn the dial to its normal setting when the ice cubes are frozen. To remove the cubes from the ice tray, hold it under running water.
10. Reversing the door hang, Fig. 7 Lay the appliance on its back. Remove the 8 screws (1). Remove the door, together with the two hinges (2), from the housing. Remove the two cover caps (3) from the housing and place them in the open hinge holes in the housing. Place the bottom righthand hinge in the top left of the door and the top righthand hinge in the bottom left of the door and hang the door on its hinges in the open cover cap holes in the housing. Secure the hinges and cover caps with the 8 screws.
12. Assembly of door handle (Fig. 11) Figure 11. 13. Customer service Before you call a service engineer, carry out the following simple tests: Problem Possible cause The appliance does not Thermostat control is set too low cool sufficiently Too much food to be cooled was put in Door is not shut properly. Refrigerator not level Internal air circulation is restricted. External air circulation is restricted.
14. Putting into operation Technical data: Model EA 3100 Type Gross volume Mains operation Input Energy consumption Climate class Refrigerant MF20-60 31 litre 100V (AC) 90W 0.97 kWh/24h N 159g H2O + 86g NH3 EA 3080 EA 3140 RA 80; RH 200 RA 140 MF20-60 MF20-60 23 litre 41 litre 100V (AC) 100V (AC) 90W 90W 0,92 kWh/24h 1.07 kWh/24h N N 159g H2O + 86g NH3 159g H2O + 86g NH3 14.1 Connecting to electrical mains The appliance may only be operated from nominal voltage mains as shown on the data plate.
Printed by Océ Hungária Kft. Rev.: 2006. 12. 04.
