User manual

6
5. Only the entire cooling unit must project into
the duct as shown
6. Air passing thr
ough the duct must not be
preheated by any source of heat
7. Ventilation grills, if used, must have an free
openings of at least 200 cm² each
The refrigerator can be fixed to the bottom of the
furniture through its fixing feet using screws of an
appropiate length. (Fig. 4)
During installation, please ensure the mains plug
is accessible at all times.
5. Using the appliance
To start the refrigerator connect the plug into a
properly earthed socket.
The cooling fins should show signs of cooling after
about 3 hours. The refrigerator needs about 6 hours
at normal ambient temperature to reach 6 °C in the
storage compartment.
5.1. Temperature regulation
The usual setting required is in the region of 2 to 3 on
the thermostat knob (Fig. 5), but this can vary with
conditions of load and installation. If it is found
necessary to alter the setting,the knob can be turned
to a higher number to produce a colder temperature,
or a lower number to produce a warmer temperature.
The effect of any adjustment can be checked by
means of the thermometer after leaving the
refrigerator operating for a further period to settle
down again.
5.2. Cooling unit control (CUC)
(Ser. No. starting with 637xxxxx or higher.)
The electronic checks the function after every
defrosting period (every 24 hours) by measuring the
evaporator temperature drop. If it registers a problem
the refrigerator will shut down and stops cooling. If this
happens you should check whether the refrigerator
has been overloaded, that the door was properly
closed, that the cooling unit ventilation is correct and
that the refrigerator is levelled. After checking, unplug
the refrigerator at least for 10 seconds and plug it in
again. This resets the unit and it will function again. If
no sign of cooling there is a problem with the cooling
unit and you should contact Dometic service.
Figure 4.
Figure 5.
