IBIS4--O.book Seite 3 Montag, 5. November 2018 7:56 19 IBIS4 Original instructions Please read this instruction manual carefully before first use, and store it in a safe place. If you pass on the product to another person, hand over this instruction manual along with it. You find the installation manual online at: “dometic.com/manuals”. The instructions in the installation manual are intended for qualified personnel at workshops who are familiar with the guidelines and safety precautions to be applied.
IBIS4--O.book Seite 4 Montag, 5. November 2018 7:56 19 Explanation of symbols 7.10 7.11 7.12 IBIS4 Activating the sleep function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17 Replacing the remote control batteries . . . . . . . . . . . . . . . . . . . . . . .17 Setting the timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18 8 Cleaning the roof air conditioner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
IBIS4--O.book Seite 5 Montag, 5. November 2018 7:56 19 IBIS4 Safety instructions In particular, the manufacturer will not be liable for any consequential damage, especially consequential damage caused by failure of the roof air conditioner. 2.1 General safety ! WARNING! AU • Electrical devices are not toys.
IBIS4--O.book Seite 6 Montag, 5. November 2018 7:56 19 Target group for this manual A NOTICE! • Never drive through automatic car washes when the roof air conditioner is mounted. • Please ask your vehicle manufacturer if a technical inspection is required after fitting an air conditioner and whether the height entered in your vehicle documents needs to be altered.
IBIS4--O.book Seite 7 Montag, 5. November 2018 7:56 19 IBIS4 5 Technical description Technical description The roof air conditioner supplies the interior with cool or warm air which is without dust and dirt and can be dehumidified. The roof air conditioner is operated with the remote control or via the control panel on the air conditioner. I 5.1 NOTE The roof air conditioner can lower the temperature within the vehicle to a certain level.
IBIS4--O.book Seite 8 Montag, 5. November 2018 7:56 19 Technical description IBIS4 2 AUTO Control and display elements (fig. 2): Symbol Explanation Switches the roof air conditioner on or to stand-by mode. + button: Increases the currently displayed value. – button: Reduces the currently displayed value. Activates the sleep function (chapter “Additional functions” on page 11). Indicates the timer is set. Displays the set temperature and indicates fan level when fan is adjusted.
IBIS4--O.book Seite 9 Montag, 5. November 2018 7:56 19 IBIS4 Technical description 5.2 Remote control All settings of the device (e. g. temperature settings, timer programming) are transmitted to the roof air conditioner by remote control. 3 1 TURBO °C/°F The following control and display elements are available on the remote control (fig. 3, page 9) : No.
IBIS4--O.book Seite 10 Montag, 5. November 2018 7:56 19 Technical description No./Button IBIS4 Explanation Switches the roof air conditioner on or to stand-by mode. + button: Increases the currently displayed value. – button: Reduces the currently displayed value. Adjusts the fan speed between Low, Med or High – showing as 1, 2 or 3 on the air outlet unit display for a short time when changed. Selects the air operation mode (chapter “Air conditioning modes” on page 10). Selects the turbo mode.
IBIS4--O.book Seite 11 Montag, 5. November 2018 7:56 19 IBIS4 Before initial use Air conditioning mode Display message Explanation Heating You specify the temperature and fan settings, and the air conditioner heats the interior to this temperature. The fan will only start after 2 min (on Low speed) and the after around 5 min will got to the set fan speed (after the evaporator reaches temperature). Dehumidification Dehumidification removes moisture from the air without heating or cooling the inside.
IBIS4--O.book Seite 12 Montag, 5. November 2018 7:56 19 Operating the roof air conditioner ! IBIS4 CAUTION! Beware of injury Do not insert your fingers or objects into the air nozzles or the intake grille. Set the time ➤ Set the current time (see chapter “Setting the time” on page 16). Set the remote control ➤ Insert the batteries (see chapter “Replacing the remote control batteries” on page 17). ✓ The display shows all symbols for 5 seconds. ✓ The remote control is ready for operation.
IBIS4--O.book Seite 13 Montag, 5. November 2018 7:56 19 IBIS4 7.2 Operating the roof air conditioner Using the remote control 4 AUTO The remote control must be pointed at the IR receiver (1) on the control panel during operation. ➤ Press a button. ✓ The value is transmitted directly to the roof air conditioner. ✓ The roof air conditioner confirms the receipt of data with a high note. Switching only the remote control to or from stand-by In stand-by mode, the remote control display shows the time only.
IBIS4--O.book Seite 14 Montag, 5. November 2018 7:56 19 Operating the roof air conditioner IBIS4 • Align the air nozzles sensibly. • Make sure the air nozzles and intake grille are not covered by cloths, paper or other objects. 7.4 I Switching the roof air conditioner on and to stand-by NOTE • When roof air conditioner is switched on, it begins to condition the air to the values that were set most recently. • The roof air conditioner can be switched ed off only by cutting mains power.
IBIS4--O.book Seite 15 Montag, 5. November 2018 7:56 19 IBIS4 7.6 Operating the roof air conditioner Selecting the fan setting manually The fan controls the strength of the air supply. In all modes, except for the “Automatic”( manually. Display message ) mode, the fan speed can be selected Explanation Three fan speeds Auto fan (changes the fan speed based on the temperature setting and actual room temperature) only available in the “Cooling” ( ) and “Heating” ( ) modes.
IBIS4--O.book Seite 16 Montag, 5. November 2018 7:56 19 Operating the roof air conditioner 7.8 IBIS4 Adjusting the air nozzles The air supply within the vehicle can be regulated by setting the air nozzles. 5 1 ➤ Turn the slats (1) in the air nozzles independently in the required directions. The air flow can be adjusted along the ceiling or towards the floor. 7.9 Setting the time The remote control needs the current time in order to program the timer.
IBIS4--O.book Seite 17 Montag, 5. November 2018 7:56 19 IBIS4 Operating the roof air conditioner 7.10 Activating the sleep function I NOTE The sleep function is only availabe in “Cooling” and “Heating” mode. When the sleep function is activated, the compressor speed and the fan speed is limited to a lower level to reduce the noise levels for easier sleeping. ➤ Set the required temperature (see chapter “Setting the temperature” on page 15). ➤ Press the button. ✓ The symbol appears in the display.
IBIS4--O.book Seite 18 Montag, 5. November 2018 7:56 19 Operating the roof air conditioner 7.12 IBIS4 Setting the timer The timer function allows you to set a specific time period for air conditioning. You can specify the switch-on time, the switch-off time or both values. I NOTE The remote control returns to its initial mode if no button is pressed on the remote control for 15 seconds while programming the timer.
IBIS4--O.book Seite 19 Montag, 5. November 2018 7:56 19 IBIS4 Cleaning the roof air conditioner Setting the switch-on and switch-off times ➤ Press the button three times. ✓ The ON symbol ( The OFF symbol ( ) flashes on the display of the remote control. ) is displayed. ✓ Use the + or – button to set the time when the roof air conditioner is to switch on. ➤ Press the button again. ✓ The OFF symbol ( ) flashes on the display of the remote control.
IBIS4--O.book Seite 20 Montag, 5. November 2018 7:56 19 Cleaning the roof air conditioner IBIS4 6 1 A NOTICE! Beware of damage The air outlet unit display screen (1) is acrylic and can be damaged by some common household chemicals. Only use a mild solution of warm soapy water to clean it. Chemical cleaners, window cleaners, alcohol, certain tensides, organic solvents, softeners and similar can damage the display.
IBIS4--O.book Seite 21 Montag, 5. November 2018 7:56 19 IBIS4 9 ! Maintenance of the roof air conditioner Maintenance of the roof air conditioner WARNING! Any other maintenance work to that which is described here may only be carried out by qualified personnel who are familiar with the risks involved when handling refrigerant and air conditioning systems as well as the relevant regulations.
IBIS4--O.book Seite 22 Montag, 5. November 2018 7:56 19 Troubleshooting IBIS4 Interval Inspection/maintenance Once per year Check the profile seals: ➤ Check the seal between the roof air conditioner and the roof of the vehicle for cracks and other damage. Once per year Have the heat exchanger serviced: ➤ Have the heat exchanger of the roof air conditioner serviced by specialist workshop. 10 Troubleshooting Problem Cause Remedy Roof air conditioner constantly switches itself off.
IBIS4--O.book Seite 23 Montag, 5. November 2018 7:56 19 IBIS4 Problem Troubleshooting Cause Not heating well The roof air conditioner is not set to heating. The ambient temperature is below –2 °C. Remedy ➤ Set the roof air conditioner to heating. The roof air conditioner is designed for best operation at ambient temperatures above –2 °C. The temperature set is lower than the ➤ Select a higher temperature. room temperature. One of the temperature sensors is defective.
IBIS4--O.book Seite 24 Montag, 5. November 2018 7:56 19 Warranty IBIS4 Problem Cause Remedy Remote control does not register. The remote control is not pointing towards the air outlet unit display. ➤ Point the remote control towards the air outlet unit display. The batteries in the remote control are empty. Note: The display of the remote control will still be bright even if the batteries are low. ➤ Replace the batteries in the remote control. 11 Warranty The statutory warranty period applies.
IBIS4--O.book Seite 25 Montag, 5. November 2018 7:56 19 IBIS4 Disposal • All product components must be disposed of (preferably recycled) in compliance with statutory legislation in the country in which disposal takes place. • For correct disposal, the appliance must be consigned to an authorised waste disposal company to ensure that all recyclable components are reused and the remaining materials are processed properly.
IBIS4--O.book Seite 26 Montag, 5. November 2018 7:56 19 Technical data IBIS4 Discharge of refrigerant into the atmosphere is against the law. Severe penalties apply. 13 Technical data Contains fluorinated greenhouse gases. Hermetically sealed equipment. IBIS4 IB36H401RI, IB36H401RIY Compressor capacity: 3600 W Cooling capacity based on ISO 5151: 2625 W Heating capacity based on ISO 5151: 3017 W Rated input voltage: 220 – 240 Vw/ 50 Hz Rated current in cooling mode: 6.
