User Manual

User Manual
MS-225OR
210*148MM
(Diagram 1)
Description of keys and DPI adjusting
Low-voltage alarming function
When battery has been used for some time and discover the LED light in
"DPI-adjusting key" blinks automatically, which reminds you that battery's
voltage is becoming low, suggested you replace the battery with new one.
System requirements
Windows 2000/XP/Vista/7
Specifications and functions
1. USB nano receiver can be stored inside battery compartment
2. 2.4GHz, operating distance up to 8 meters
3. Power ON/OFF function
4. Low-voltage alarming function
5. Resolution: 1200DPI adjustable
Scrolling wheel
Left key
Right key
(Diagram 2)
ON/OFF switch
Battery cover
Position for storing
receiver
Package contents
Wireless Optical Mouse
USB receiver
2 AAA alkaline batteries
User manual
Installing the battery (Diagram 1)
Whenever new batteries are installed, make sure that they are fresh 1.5V
AAA batteries.
A)Remove the battery cover.
B) Insert two AAA batteries into the battery compartment, make sure to properly
orient the positive (+) and negative (-) ends as specified by the marks in the
battery compartment. Replace the battery cover and make sure it is locked.
C)Switch on the mouse, the LED in bottom of mouse will blink.
Installing the receiver (Diagram 2)
The codes of receiver and mouse were successfully connected in factory.
User can directly use the complete set of products, no worry about the code
connecting.
A)Insert receiver into USB port of PC, the computer system will automatically
detect it and prepare it for full operation.
B)The mouse may use then.
If the user wrongly operates, please redo the above operating procedures.
"ON/OFF" switch (Diagram 1)
Without using the mouse, user may turn off it by "ON/OFF" switch for saving
battery power.
(1) 15.21 statement
changes or modifications not expressly approved by the party responsible
for compliance could void the user s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:(1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation.
