Vigor2930 Series Dual-WAN Security Firewall Quick Start Guide Version: 1.
Copyright Information Copyright Declarations Copyright 2007 All rights reserved. This publication contains information that is protected by copyright. No part may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language without written permission from the copyright holders. Trademarks The following trademarks are used in this document: z Microsoft is a registered trademark of Microsoft Corp.
European Community Declarations Manufacturer: Address: Product: DrayTek Corp. No. 26, Fu Shing Road, HuKou County, HsinChu Industrial Park, Hsin-Chu, Taiwan 303 Vigor2930 Series Router DrayTek Corp. declares that Vigor2930 Series of routers are in compliance with the following essential requirements and other relevant provisions of R&TTE Directive 1999/5/EEC.
Table of Contents 1. Introduction........................................................................................................... 1 1.1 Panel Explanation ...................................................................................................................... 2 1.1.1 For Vigor2930 ............................................................................................................... 2 1.1.2 For Vigor2930n .......................................................................
1. Introduction Vigor2930 is a broadband router with dual-WAN interface. It provides policy-based load-balance, fail-over and BOD (Bandwidth on Demand), also it integrates IP layer QoS, NAT session/bandwidth management to help users control works well with large bandwidth.
1.1 Panel Explanation 1.1.1 For Vigor2930 LED Status Explanation ACT (Activity) CSM Blinking Off On Blinking On CPA (Content Portal Authority) On WAN1/2 On Blinking On Blinking On On The router is powered on and running normally. The router is powered off. The DoS/DDoS function is active. It will blink while deleting an attack. The profile of CSM (Content Security Management) for IM/P2P application is active. (It is enabled from Objects Setting >> CSM Profile). The Web Content Filter is active.
1.1.2 For Vigor2930n LED Status Explanation ACT (Activity) Blinking Off On Blinking On On Blinking On Blinking On Blinking On On The router is powered on and running normally. The router is powered off. The DoS/DDoS function is active. It will blink while deleting an attack. The profile of CSM (Content Security Management) for IM/P2P application is active. (It is enabled from Objects Setting >> CSM Profile). Wireless access point is ready. It will blink while wireless traffic goes through.
1.1.3 For Vigor2930Vn LED Status Explanation ACT (Activity) Blinking Off On Blinking On On Blinking On Blinking On Blinking On Off Blinking The router is powered on and running normally. The router is powered off. The DoS/DDoS function is active. It will blink while deleting an attack. The profile of CSM (Content Security Management) for IM/P2P application is active. (It is enabled from Objects Setting >> CSM Profile). Wireless access point is ready. It will blink while wireless traffic goes through.
1.1.4 For Vigor2930VS LED Status Explanation ACT (Activity) CSM Blinking Off On Blinking On CPA (Content Portal Authority) On WAN1/2 On Blinking On Blinking On Off Blinking The router is powered on and running normally. The router is powered off. The DoS/DDoS function is active. It will blink while deleting an attack. The profile of CSM (Content Security Management) for IM/P2P application is active. (It is enabled from Objects Setting >> CSM Profile). The Web Content Filter is active.
(Green) Right LED (Green) Off Blinking On Off The port is disconnected. The data is transmitting. The port is connected with 100Mbps. The port is disconnected with 10Mbps. Interface Description Factory Reset Restore the default settings. Usage: Turn on the router (ACT LED is blinking). Press the hole and keep for more than 5 seconds. When you see the ACT LED begins to blink rapidly than usual, release the button. Then the router will restart with the factory default configuration.
1.1.5 For Vigor2930VSn LED Status Explanation ACT (Activity) Blinking Off On Blinking On The router is powered on and running normally. The router is powered off. The DoS/DDoS function is active. It will blink while deleting an attack. The profile of CSM (Content Security Management) for IM/P2P application is active. (It is enabled from Objects Setting >> CSM Profile). Wireless access point is ready. It will blink while wireless traffic goes through. The WAN1 or WAN2 connection is ready.
Right LED (Green) Blinking On Off The data is transmitting. The port is connected with 100Mbps. The port is disconnected with 10Mbps. Interface Description Factory Reset Restore the default settings. Usage: Turn on the router (ACT LED is blinking). Press the hole and keep for more than 5 seconds. When you see the ACT LED begins to blink rapidly than usual, release the button. Then the router will restart with the factory default configuration. Restart the router forcefully. Connecters for PSTN phones.
1.2 Package Content nQuick Start Guide oCD p RJ-45 Cable (Ethernet) q RJ-45 to RJ-45 Cable for S models r ISDN Phone Adapter s The type of the power adapter depends on the country that the router will be installed: UK-type Power Adapter EU-type Power Adapter USA/Taiwan-type Power Adapter AU/NZ-type Power Adapter * The maximum power consumption is 17-23 Watt.
This page is left blank.
2. Installing Your Router This section will guide you to install the router through hardware connection and configure the router’s settings through web browser. 2.1 Hardware Installation Before starting to configure the router, you have to connect your devices correctly. 1. Connect the cable Modem/DSL Modem/Media Converter to any WAN port of router with Ethernet cable (RJ-45). The WAN1/WAN2 LED (Left or Right) will light up according to the speed (100 or 10) of the device that it connected. 2.
2.2 ISDN Phone Adapter Installation Such information is provided for Vigor2930 S models (e.g., Vigor2930VS). ISDN S0 1 is always fixed to connect ISDN phone. However, ISDN S0 2 is configurable as NT (ISDN S0 intern) or TE (ISDN S0 extern) mode. When the user configures ISDN S0 2 as NT mode in VoIP>> Phone Settings, the orange LED will light on to indicate ISDN2-S0 is selected.
3. Configuring Web Pages To access Internet, please finish basic configuration after completing the hardware installation. 3.1 Basic Configuration The Quick Start Wizard is designed for you to easily set up your router for Internet access. You can directly access the Quick Start Wizard via Web Configurator. 1. Make sure your PC connects to the router correctly.
4. Enter the login password on the field of New Password and retype it on the field of Retype New Password. Then click Next to continue. 5. On the next page as shown below, please select the WAN interface that you use. Choose Auto negotiation as the physical type for your router. Then click Next for next step. 6. On the next page as shown below, please select the appropriate Internet access type according to the information from your ISP.
PPPoE: if you click PPPoE or PPPoA as the protocol, please manually enter the Username/Password provided by your ISP. Then click Next. PPTP: if you click PPTP, you will get the following page. Please type in all the information originally provided by your ISP. Then click Next for next step. Static IP: if you click Static IP, you will get the following page. Please type in the IP address information originally provided by your ISP. Then click Next for next step.
DHCP: if you click DHCP, you will get the following page. Simply click Next to continue. 7. Now you can see the following screen. It indicates that the setup is complete. Different types of connection modes will have different summary. Click Finish and then restart the router. Afterward, you will enjoy surfing on the Internet.
3.2 Wireless Configuration For the user of Vigor2930/2910VS, please skip this section. For operating Vigor2930n/Vn/VSn well, it is necessary for you to set the wireless LAN settings for using wireless function. Please read the following section carefully for configuring the settings for this router. (The default value of Frequency Domain was set by factory depends on the reselling region.) 3.2.
3. At present, the router can connect to IEEE802.11b, IEEE802.11g and IEEE802.11n stations simultaneously. Simply choose Mix (11b+11g+11n) mode. 4. Type in the name of the SSID. The default name for SSID is default. We suggest you change it to a particular name for your necessity. SSID (service set identifier) It is used to name the wireless LAN for this router, and it must have the same content in client PC/notebook wireless card(s). SSID can be any text numbers or various special characters.
router, please select any one of the encryption mode here. WEP Only Accepts only WEP clients and the encryption key should be entered in WEP Key. WEP/802.1x Only Accepts only WEP clients and the encryption key is obtained dynamically from RADIUS server with 802.1X protocol. WPA/PSK Only Accepts only WPA clients and the encryption key should be entered in PSK. WPA/802.1x Only Accepts only WPA clients, and the encryption key is obtained dynamically from RADIUS server with 802.1X protocol.
This page is left blank.
4. Trouble Shooting This section will guide you to solve abnormal situations if you cannot access into the Internet after installing the router and finishing the web configuration. Please follow sections below to check your basic installation status stage by stage. ¾ Checking if the hardware status is OK or not. ¾ Checking if the network connection settings on your computer are OK or not. ¾ Pinging the router from your computer. ¾ Checking if the ISP settings are OK or not.
4.2 Checking If the Network Connection Settings on Your Computer Is OK or Not Sometimes the link failure occurs due to the wrong network connection settings. After trying the above section, if the link is stilled failed, please do the steps listed below to make sure the network connection settings is OK. For Windows The example is based on Windows XP. As to the examples for other operation systems, please refer to the similar steps or find support notes in www.draytek.com. 1.
4. Select Obtain an IP address automatically and Obtain DNS server address automatically. For MacOs 1. Double click on the current used MacOs on the desktop. 2. Open the Application folder and get into Network. 3. On the Network screen, select Using DHCP from the drop down list of Configure IPv4.
4.3 Pinging the Router from Your Computer The default gateway IP address of the router is 192.168.1.1. For some reason, you might need to use “ping” command to check the link status of the router. The most important thing is that the computer will receive a reply from 192.168.1.1. If not, please check the IP address of your computer. We suggest you setting the network connection as get IP automatically. (Please refer to the section 4.2) Please follow the steps below to ping the router correctly.
4.4 Checking If the ISP Settings are OK or Not Open WAN >> Internet Access page and then check whether the ISP settings are set correctly. Click Details Page of WAN1/WAN2 to review the settings that you configured previously. For PPPoE Users 1. Check if the Enable option is selected. 2. Check if Username and Password are entered with correct values that you got from your ISP.
For Static Users 1. Check if the Enable option for Broadband Access is selected. 2. Check if WAN IP Network Settings is set appropriately. 3. Check if IP Address, Subnet Mask and Gateway are set correctly (must identify with the values from your ISP) if you choose Specify an IP address. For PPTP Users 1. Check if the Enable option for PPTP Link is selected. 2. Check if PPTP Server, Username, Password and WAN IP address are set correctly (must identify with the values from your ISP).
4.5 Backing to Factory Default Setting If Necessary Sometimes, a wrong connection can be improved by returning to the default settings. Try to reset the router by software or hardware. Warning: After pressing factory default setting, you will loose all settings you did before. Make sure you have recorded all useful settings before you pressing. The password of factory default is null. Software Reset You can reset the router to factory default via Web page.
4.6 Contacting Your Dealer If the router still cannot work correctly after trying many efforts, please contact your dealer for further help right away. For any questions, please feel free to send e-mail to support@draytek.com.
