Instruction manual

9
LCD5500(Z) Keypad:
The Liquid Crystal Display (LCD) displays prompts and
system information on two 16 character lines.
If “< >” appears, more information can be accessed by
using the arrow (< >) keys. Press [<] to see the previous
function or item of information. Press [>] to advance the
display to next function or item of information.
Press the keys on the number pad as prompted by the
LCD display to view alarms or troubles, to arm and disarm
the system and to bypass zones.
To exit a function and return to the Ready state, press [#];
to select a function press [
Q].
NOTE: All functions can be performed from any LCD
keypad by using the LED keypad commands, as well
as by scrolling through the message display.
Important Note: Test system weekly and have any system
trouble conditions corrected by your alarm installer.
All Keypads:
Function Keys
(Stay, Away, Chime, Reset, Exit):
If activated by your installer, these
keys allow easy single button
activation of the most commonly used
features. For more information, talk to
your alarm installer.
Press both Keys for two seconds
to send a FIRE transmission.
Press both
Keys for two seconds
to send an AUXILIARY transmission.
Press both
Keys for two seconds
to send a PANIC transmission.
NOTE
(All Keypads) : The Fire,
Auxiliary and Panic keys will NOT
function unless programmed by the
installer. If these keys are in service
and the installer has enabled audible
feedback, holding down the key for
two seconds will cause the keypad
sounder to beep indicating that the
input has been accepted and
transmission is underway.
LCD5500(Z) Keypad
Fire Light (LED keypads only) :
If the Fire light is ON, a fire alarm has
occurred (See “Fire Alarm Operation”
on page 14).
Program Light (LED keypads only) :
The Program light will flash you are
programming access codes, setting the
system time or performing other
programming functions. If someone is
programming at another keypad, the
Program light will turn ON to indicate
that the system is busy.
