5 Technical specifications
5.1 Electrical specifications
Item Description
Network Processor Plug&Play network processor for remote Amplifier/ DSP control over Ethernet networks.
Support of DHCP, Auto IP and mDNS for automatic addressing.
Digital Signal Processor On board DSP for gain, parametric equalizer, matrix mixing, phase, compressor limiter, delay,
RMS meters
Balanced audio input Two analog balanced audio inputs on Neutrik XLR connectors, 1 analog link out for channel 1
Max input selectable by internal jumper setting: 20dBu or 8dBu
Audio over Ethernet (optional) Audio Video Bridging (AVB) for streaming of low latency, un-compressed audio over Ethernet
networks
Supports IEEE standards: 802.1as, 802.1Qat, P1722
Audio streaming capability: up to 3 input streams and up to 3 output streams (link out over
AVB)
Power ratings (RMS @ 1% THD) Channel 1: 800W @16Ω, 1550W @8Ω, 2400W @4Ω, 4000W Peak
Amplifier module specifications THD (typical): < 0,05 % (20 Hz - 20 kHz, 8 Ω load, 3 dB below rated power)
Frequency response: 20Hz - 20kHz +/- 0.15dB (8 Ω load, 1 dB below rated power)
Damping factor > 1000 (8 Ω load, 1 kHz and below)
Audio source selection Selectable by software/ hardware between analog source and network source (AVB option)
Protection circuits Input limiter, short circuit protection, DC protection of output, under & over voltage protection,
intelligent mains fuse protection, power stage overload protection, temperature protection of
transformers and heat-sinks
Real time readouts from interface Clip, Protect mode, Output voltage, Output current, Heatsink temperature
Front Panel LED Power, Thermal, Network activity, Clip LED
Front Panel controls Rotary volume control (0-100%)
Amplifier audio source selection (Network or Analog)
Front panel connectors Two Ethercon Neutrik connector for network connectivity (RJ45 compatible)
Two Neutrik XLR female connectors for analog inputs
One Neutrik XLR male for analog Link Out
One Powercon Neutrik connector for Main AC in
One Powercon Neutrik connector for Main link out
Universal Mains power 95 ~ 240VAC
Weight 4.5 kg
Dimensions (H x W x D) mm 410 x 171 x 138.5 mm (16.3” x 6.7” x 5.5”)
