DP295 ( CAT NO : 16 - 3266 ) DVD / VCD / CD / MP3 PLAYER OPERATION INSTRUCTION OPEN CLOSE DVD/VCD/CD/MP3 PLAYER POWER PLAY PAUSE STOP STANDBY
WARNING - TO PREVENT FIRE OR SHOCK HAZARD, DO NOT USE THIS PLUG WITH AN EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE. - TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
TABLE OF CONTENTS Introduction page 4 ~ 5 * Remote control * Front panel * Back panel Connections * * * * * * page 17 * Cleaning the components * Notes about compact disc ( DVD video CD, video CD, audio CD, MP3 CD) * Notes about the CD player page 6 ~ 7 * Direct connection with a TV * Inserting batteries into the remote control Basic Functions Care and maintenance Troubleshooting page 18 Electrical specifications page 19 page 8~ 9 Basic play Basic playback Slow motion play Fast search Pictur
Introduction Please refer to PAGE 5 for remote control functioning details.
Introduction Remote Control POWERkey Turn the system POWER ON or STANDBY NUMBER keys (0~9 ) Select the items or settings directly. SETUP key Display or exit the SETUP menu. key / / Plays backward quickly (fast search). / key PREV key Select and move the screen cursor to desired option. Press to select the previous title, chapter or track. VOLUME (+ / -) keys Increase / decrease the master volume level. ANGLE key Select the angles cyclicity.
Connections Direct Connection with a TV CR CB Y COMPONENT VIDEO OUT AC ~ 110-220V 50/60Hz R AUD IO L OU T VID EO S-VIDEO OUT COAXIAL You must connect a TV to the DVD system in order to use DVD player. You can connect other audio and audio / visual components to the DVD system in order to use the Home Cinema Audio system’ s surround sound capabilities. Important! - There are various ways to connect the system to a TV (as shown in the illustration). You only need to make one of best connections.
Connections Inserting Batteries into the Remote Control You can control the system using the supplied remote control. Insert two AA batteries (not include) by matching the + and - on the batteries. When using the remote control, point it at the remote sensor on the front panel of this system. Note - Do not leave the remote in an extermely hot or humid place. - Do not use a new battery with an old one. - Do not drop any foreign object into the remote casing, particularly when replacing the batteries.
Basic Functions Disc information Basic Playback CAUTION! - Do not move the disc player during playback, as doing so may damage the DVD system. - Do not push on the disc tray or put any objects other than disc on the disc tray. Doing so may cause the disc player malfunction. Start playback Press PLAY/PAUSE /ll . To pause playback, press /ll again. 1 When you complete all the connections, plug the AC power cord of the player and subwoofer.
Basic Functions Fast search Angle selection 1 Press and hold / more than 1 second to fast reverse or fast forward. For DVD / MP3 discs FF(fast forward) : FF x 2 FF x 4 FF x 6 FF x 8 FF OFF. FR(fast reverse) : FR x 2 FR x 4 FR x 6 FR x 8 FR OFF. Some DVD discs contain scenes which have been taken photos simultaneously from a number of different angles. For these discs, the same scenes can viewed from each of the different angles. (The recorded angles differ from disc to disc.
Operations General setup 1 Press SETUP to enter SETUP MENU. 2 Use / / / 16:9 (Wides creen) to select your preferred option. 3 Press OK to confirm a highlighted selection. 4:3 LB (Letter Box) 4 To exit setup menu, press SETUP. 4:3 PS (Pan Scan) Setting the Picture TV SHAPE 4:3 PS VIDEOOUT AUTO TV SHAPE S-VIDEO SCR SAVER OFF GO TO PICTURE SETUP PAGE * TV Shape Select the aspect ratio of the TV to be connected.
Operations * Screen Saver If set to ON, when you leave the system in stop or pause mode for more than one minute, the screen saver will be activated. The default setting is “ OFF” . Setting the sound * Test Tone (disc mode only) If set to ON, the system will test the speaker settings. The test signal is generated through the left , right speakers. The default setting is “ OFF ” .
Operations Setting the Features PARENTAL PASSWORD MENULANG DEFAULTS PARENTAL 1G PASSWORD CHANGE MENULANG ENGLISH DEFAULTS RESET Parental Enables setting of playback limitation level. Some DVDs may have a parental level assigned to the complete disc or to certain scenes on the disc. The rating levels are 1G, 3G, 4PG-13, 6PG-R, 7NC-17, 8 ADULT, NO PARENTAL and are country dependent.
Operations Changing sound track language Special DVD / VCD features This operation works only on DVDs with multiple soundtrack language. A number of operations can be carried out directly via the multiple menu bars on the TV screen without interrupting disc playback.
Operations Moving to another chapter / title Repeat play Some discs may contain more than one title or chapter. If the disc has a title or chapter menu recorded on it, you can start playback from the selected item. You can only select the repeat play mode during playback. 1 Select (chapter) or (title) from the menu bar. REPEAT 2 Use number keypad (0~9) to select a desired title / chapter number and press OK to start playback.
Operations Program play You can play the contents of the disc in the order you want by programming the order of the tracks to be played. Up to 99 tracks can be stored. PROGRAM 1 Select in the menu bar and press key to enter program mode. ” is displayed. - “ 2 Use the number keypad (0~9) to input the track number in the order you want. - If you attempt to program more than 99 tracks, “ ” is displayed. 3 Press OK to store the track. - Repeat steps 2-3 to store other tracks.
Special Functions Sleep timer setting The sleep timer enables the system to switch to standby mode automatically at a preset time . 1 Press SLEEP repeatedly to select a preset time. - The selections are as follows (time in minutes) 15 30 45 60 90 120 OFF 15... 2 When you reach the desired length of time, stop pressing the SLEEP button. 3 To check the remaining length of time after sleep timer is activated. Press SLEEP once.
Care and Maintenance Cleaning the components Before cleaning, switch off the DVD receiver and unplug the subwoofer from the mains. Clean all components using a wet cloth or a tittle synthetic clean er. Solvents, spirits, dilutents, etc, can damage the surface of the device. Notes about compact disc (DVD video CD, video CD, audio CD, MP3 CD) Always keep the CD in its cover and touch the edges only. The surface shimmering in rainbow colours must not be touched and should always be kept clean.
Tr oub leshooting oubleshooting If you experience any of the following difficulties while using the system, use this troubleshooting guide to help you remedy the problem. Should any problem persist, consult your nearest service center. No power • Is the power cord firmly plugged into the power outlet? • One of the safety mechanisms may be operating. In this event, unplug the player from the power outlet briefly and then plug it in again. No picture • Check that the system is connected securely.
Electrical Specification DVD Player Pickup ......................................................................................... Semiconductor laser, Wavelength 650 mm Signal system ............................................................................................................................. NTSC / PAL Video signal horizontal resolution ......................................................................................... 480 lines (DVD) Video signal-to-noise ratio ....................
Limited Ninety-Da y War Ninety-Day arrr anty This product is warranted by RadioShack against manufacturing defects in material and workmanship under normal use for ninety (90) days from the date of purchase from RadioShack companyowned stores and authorized RadioShack franchisees and dealers.
