XR4120 INSTALLATION/OWNER'S MANUAL AM/FM Receiver with Detachable Face
XR4120 INSTALLATION Preparation Please read entire manual before installation. Before You Start • Disconnect negative battery terminal. Consult a qualified technician for instructions. • Avoid installing the unit where it would be subject to high temperatures, such as from direct sunlight, or where it would be subject to dust, dirt or excessive vibration. Getting Started • Remove trim ring from unit. • Remove 2 transit screws located on top of the unit.
XR4120 INSTALLATION Wiring Diagram Antenna Connector 10 AMP AGC Fuse FUSE When replacing the fuse, make sure new fuse is the correct type and amperage. Using an incorrect fuse could damage the radio. The XR4120 uses one 10 amp AGC fuse located in-line.
XR4120 OPERATION Control Locations - Receiver 1 18 4 2 17 3 16 4 5 15 14 13 12 11 10 9 8 1 Release 10 Preset 3 / Intro 2 Power 11 Preset 2 / Random 3 Volume Knob 12 Preset 1 / Repeat 4 Audio / Menu 13 Display 5 USB Port 14 Tune Up 6 Auxiliary Input 15 Tune Down 7 Preset 6 / Folder Up 16 Band / Go Back 8 Preset 5 / Folder Down 17 Mode 9 Preset 4 / Play / Pause 18 Mute 7 6
XR4120 OPERATION Control Locations - Remote 1 2 3 17 4 16 5 15 6 14 7 13 8 12 9 11 10 1 Power 10 Preset 6 / Folder Up 2 Volume Up 11 Preset 5 / Folder Down 3 Select 12 Preset 4 / Play / Pause 4 Tune Up 13 Preset 1 / Repeat 5 Volume Down 14 Preset 2 / Random 6 Audio / Menu 15 Mode 7 Display 16 Band / Go Back 8 Mute 17 Tune Down 9 Preset 3 / Intro 5
XR4120 OPERATION General Operation Faceplate Removal Power On/Off Mode Display Press RELEASE and pull away from the left side to remove. To re-install, insert right side of faceplate first then push left side to secure. Press or any other button to turn the unit on. Press again to turn the unit off. Press MODE to select between AM/FM, USB, SD or auxiliary input modes. Modes of operation are indicated in the display.
XR4120 OPERATION General Operation Audio / Menu Press the volume knob to select between Bass, Treble, Balance, Fader, Loudness, Distance and Stereo. BASS TREBLE BALANCE FADER LOUDNESS Bass Press the volume knob until BAS appears. Rotate the volume knob left/right to adjust. (-7 minimum / +7 maximum) Treble Press the volume knob until TRE appears. Rotate the volume knob left/right to adjust. (-7 minimum / +7 maximum) DISTANCE STEREO Balance Press the volume knob until BAL appears.
XR4120 OPERATION AM/FM Tuner Operation Press TUNE nn or TUNE ll momentarily to seek to the Seek Tuning next strong station. Press and hold TUNE nn or TUNE ll until "MANUAL" Manual Tuning appears, then press TUNE nn or TUNE ll momentarily to change radio frequency up or down one step at a time. Press and hold to advance quickly. Band Storing and Recalling Station Presets Press BAND to select between FM1, FM2, FM3, AM1 and AM2 bands. Up to 18 FM stations and 12 AM stations can be stored.
XR4120 OPERATION USB / SD Card Operation Repeat Random Intro Character Support Media Compatibility Press RPT to choose between: • Current Song - Continuously repeats selected track. • Current Folder - Continuously repeats all files in folder. Press RDM to choose between: • Off - Cancels RDM function. • All Songs - Plays all tracks in random order. • Current Folder - Plays all tracks in folder in random order.
XR4120 OPERATION USB / SD Card Operation Playback Capacity • Maximum number of files: 1024 • Maximum number of folders: 512 • Maximum number of folder levels (sub folders): 8 Note: If the number of files/folders exceeds the maximum outlined above, the additional files/folders will be ignored. Note: Devices that exceed the maximum number of files or folders may not function properly. USB Device Compatibility Due to the differences of USB devices, some devices may not be compatible.
XR4120 OPERATION Troubleshooting Problem Unit will not turn on (no power) Unit has power (but no sound) Cause Action Yellow wire not connected or incorrect voltage Red wire not connected or incorrect voltage Black wire not connected Fuse blown Speaker wires not connected Check connections for proper voltage (11~16VDC) One or more speaker wires touching each other or touching chassis ground Check connection to ground Replace fuse Check connections at speakers Insulate all bare speaker wires from ea
XR4120 OPERATION Limited One Year Warranty This warranty gives you specific legal rights. You may also have other rights which vary from state to state. Dual Electronics Corp. warrants this product to the original purchaser to be free from defects in material and workmanship for a period of one year from the date of the original purchase. Dual Electronics Corp.
XR4120 OPERATION FCC Compliance This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
XR4120 OPERATION Specifications FM Tuner Tuning range: 87.5MHz-107.9MHz Usable sensitivity: 10dBf 50dB quieting sensitivity: 25dbu Stereo separation @ 1kHz: >30dB Frequency response: 30Hz-13kHz AM Tuner Tuning range: 530kHz-1710kHz Usable sensitivity: <42dBu Frequency response: 30Hz-2.2kHz General Speaker output impedance: 4~8 ohms Line output voltage: 2 Volts RMS Dimensions: 7" x 7" x 2" (178 x 178 x 50 mm) Design and specifications subject to change without notice.
XR4120 OPERATION Notes 15
