Camera 335B Visual Presenter User’s Guide UG335B122209V1 English - 0
Contents Chapter 1 Precautions .................................................................................... 3 Safety Precautions ....................................................................................... 4 FCC Warning................................................................................................ 4 Chapter 2 Package Contents.......................................................................... 5 Chapter 3 Product Overview .............................................
7.6 Turning the Lamp on/off ................................................................... 18 7.7 Automatically Adjusting the Image to Optimal Brightness and Focal Length 18 7.8 Freezing Images............................................................................... 18 7.9 Capturing Images ............................................................................. 18 7.10 Browsing Captured Images .............................................................. 18 7.
Chapter 1 Precautions Always follow these safety instructions when setting up and using the Document Camera: 1. Please do not tilt the machine while using. 2. Do not place the Document Camera on an unstable trolley, stand or table. 3. Do not use the Document Camera near water or source of heat. 4. Use attachments only as recommended. 5. Use the type of power source indicated on the Document Camera.
If liquid is spilled into it or the Document Camera has been exposed to rain or water. z Safety Precautions Warning: To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture. This Document Camera has a 3-wire AC line Plug. This is a safety feature to ensure that the plug will fit into the power outlet. Do not try to defeat this safety feature. If the Document Camera will not be used for an extended time, unplug it from the power outlet.
Chapter 2 Package Contents Camera 335B User Guide CD Remote Control Warranty Card VGA Cable USB Cable C-Video Cable Power Cord Appearance may vary in different countries English - 5
Chapter 3 Product Overview 1. Gooseneck 2. Lamp 3. Control panel 4. LED indicator 5. Remote sensor 6. Lens 7.
3.1 Positioning the Presenter and Document 3.2 Correct Usage * About 400mm distance between camera and the desktop is recommended.
Chapter 4 Installation and Connections 4.
4.2 Connecting to External Devices 4.2.1 Step 1: Connect the power cord from the AC In on the Camera 335B to the power outlet AC Outlet : Appearance of the power cord may vary depending on country/region. 4.2.2 Step 2: Connection projector with other hardware devices ¾ Connecting to a Projector or Monitor z Connect the VGA cable from the VGA OUT port on the Camera 335B to the VGA IN port on the projector or monitor. ¾ Connecting to a TV 1.
2. Adjust DIP Switch Setting NTSC: U.S.A., Taiwan, Panama, Philippine, Canada, Chile, Japan, Korea and Mexico. 1 2 3 4 3 4 PAL: Country/region not listed above. 1 2 The on-screen display (OSD) is not available in C-VIDEO. Some functions are not available on the control panel and the remote control in this mode. VGA OUT is not supported once C-VIDEO is enabled. 3. DIP switch settings will not available until the Camera 335B has been restarted. ¾ Connecting to a Computer 1.
2. Connect the VGA cable from the VGA IN port on the Camera 335B to the VGA OUT port on the computer. 3. Connect the RS-232 Adapter (Optional) to the RS-232 port on the Camera 335B and the RS-232 port on the computer. 4.3 Getting Started Control panel Remote Control z To turn on the Camera 335B with the remote control, aim at the remote sensor at the Camera 335B and press the Power button. z Once the Camera 335B is powered on, the LED on the projector will flash a few times and then remain lit.
Chapter 5 DIP Switch : You must restart the Camera 335B in order for DIP switch configuration to take effect. 5.1 Connecting to a Projector or Monitor 5.1.1 SXGA output (factory default): 5.1.2 WXGA output 5.1.3 XGA output 5.1.
5.2 Connecting to a TV 5.2.1 NTSC Settings: U.S.A., Taiwan, Panama, Philippines, Canada, Chile, Japan, Korea, and Mexico 5.2.2 PAL Settings: Countries/regions not listed above VGA OUT is not supported once C-VIDEO is enabled.
Chapter 6 Introduction to Control Panel/ Remote Control Buttons and On-Screen Menu 6.1 Functions of Control Panel and Remote Control Buttons The functions below are listed alphabetically Name g,h,i,j AF AUTO TUNE BRT+/CAPTURE DELETE ENTER FREEZE MENU PAN PBP PLAYBACK ROTATE SLIDE SHOW SOURCE ZOOM +/- Function Descriptions Turns the visual presenter on and off. Moves up, down, left or right to select the needed function.
6.2 On-screen Menu Press [Menu] on the remote control or control panel to enter the on-screen menu, The bold underlined values in the following table are defaults. 1st Level Major Items Display Storage 2nd Level Sub items 3rd Level Adjustment Values Function Descriptions Auto Tune Enter Press [ENTER] to automatically adjust to the optimal brightness and focal length. Focus 0~Max Use the left and right arrow keys to adjust focal length.
Setting Auto Erase ON/OFF Use the left and right arrow keys to enable/disable the auto erase function, which automatically deletes all stored images upon system shutdown. USB Transfer Camera/Storage Device Use the left and right arrow keys to select the USB transfer mode. Lamp ON /OFF Use the left and right arrow keys to turn the lamp on/off. AE ON /OFF Use the left and right arrow keys to turn the Auto Erase (AE) on/off.
Chapter 7 Descriptions of Major Functions 7.1 Switching Image Sources Live image is the default image source. Press [SOURCE] on the remote control or control panel to switch between image sources: 1. Live images (default). 2. PC. 7.2 Making Text Clearer and Photos More Colorful Photo (Photo mode) is selected by default in the [Photo/Text/Gray] mode z [Photo] (Default): View photos or text with photos in this mode to enhance colors in photos. z [Text]: View text files in this mode to make text clearer.
brighter. 2. From the Remote Control or Control Panel, press [BRT-] to darken the image. 7.6 Turning the Lamp on/off From the remote control or control panel: 1. Press [MENU] to enter the on-screen menu. 2. Press [f] or [e] to select [Setting]. 3. Press [d] to select [Lamp] modes. 4. Press [f] or [e] to turn [ON]/[OFF]. 5. Press [MENU] to exit. 7.7 Automatically Adjusting the Image to Optimal Brightness and Focal Length From the remote control: 1.
2. Press [c] or [d] or [e] or [f] to select the thumbnail you want you browse. 3. Press [ENTER] to access the full-screen display of the image. 4. Press [f] or [e] to browse the through saved images. 5. Press [PLAYBACK] to exit. 6. Press [MENU] to exit. 7.11 Deleting Captured Images From the remote control: 1. Press [PLAYBACK]. 2. Press [c] or [d] or [e] or [f] to select the desired thumbnail for deletion. 3. Press [DELETE] to delete the selected file. 4. Press [MENU] to exit. From the control panel: 1.
7.13 Panning Across a Live Image (PAN) Panning and zooming are not available in Microscope Mode. From the remote control: 1. Press [PAN] on the remote control to zoom in a part of a live image. 2. Press [c] or [d] or [e] or [f] to move around the partially zoomed-in image. 3. Press [PAN] to exit the partially zoom in mode. From the control panel: 1. Press [MENU] to enter the on-screen menu. 2. Press [f] or [e] to select the [Display] menu. 3. Press [d] to select [PAN]. 4.
7.14.3 Start/Pause/Stop Playing Images Images over 8MB cannot be played. During playback, the [ROTATE] function can be activated to rotate the images. From the remote control: 1. Press [SLIDE SHOW] to start playback. 2. Press [ENTER] to pause playback. 3. Press [ENTER] again to continue playback. 4. Press [SLIDE SHOW] again to stop playback. From the control panel: 1. Press [MENU] to enter the on-screen menu. 2. Press [f] or [e] to select the [Storage] menu. 3. Press [d] to enable [Slide Show]. 4.
5. Press [f] or [e] to move the selected image left or right. 6. Press [ZOOM+/-] to zoom in/out from the live image 7. Press [PBP] to return to the stored image screen. 8. Press [MENU] to exit. From the control panel 1. Press [MENU] to enter the on-screen menu. 2. Press [f] or [e] to select the [Display] menu. 3. Press [d] to select [PBP]. 4. Press [PBP] to enter the photo selection screen. 5. Press [S] or [T] or [e] or [f] to select the desired file for comparison. 6.
7.17.1 Inserting a Photo in the MS-Paint Application 1. Click [File> From Scanner or Camera] in the MS-Paint application as shown in the bottom left figure. 2.Click on [Get Picture] to finish, as shown in the top right figure. 7.17.2 Inserting a Photo in a Microsoft Word Document 1. Click [Insert / Image / From Scanner or Camera] in the Microsoft Word application. 2. Select [Visual Presenter V2] and click [Custom Insert].
3. Click [Get Picture] to finish. 7.17.3 Changing the Setting of the Camera 335B and then Capturing a Photo in Microsoft Word 1. Click [Insert /Image /From Scanner or Camera] in Microsoft Word. 2. Select [Visual Presenter V2 TWAIN] and click [Custom Insert].
3. A window displaying a live image (see below) will appear. 4. Press [Setting]: When the Camera Settings window pops up, the live image can be adjusted. The operation is identical from both the remote control and the control panel. Refer to Chapter 6 Control Panel/Remote Control Buttons and On-screen Menu for more information. 5. Press [Capture] to capture images in Microsoft Word. 6. Press [Cancel] to exit. 7.17.
n o p Call your desired contact. When both parties are connected, Skype will display the video screen.
7.17.5 Setting the Camera 335B as a PC Camera 1. Open My Computer and click on [Visual Presenter V2] to display a live image.
Chapter 8 Connecting to a Microscope 1 Mount the microscope adaptor (optional) in the accessories pack onto the microscope The Microscope adapter fits eyepieces of about Ø28.4mm. 2 Connect the lens of the Camera 335B to the microscope adaptor. 3 Select the Microscope mode 3.1. From the control panel or remote control 3.1.1. Press [MENU] to enter the on-screen menu. 3.1.2. Press [f] or [e] to select [Display]. 3.1.3. Press [d] to select among [Mode] modes. 3.1.4.
Chapter 9 Software instructions Using the Camera with a computer. After installing the B-WORKS, you can use the software to: ¾ Control the Camera 335B. ¾ Capture and record images. ¾ Annotate images, highlight important details and save them for later use. ¾ Use the full-screen function. 9.1 System Requirements Windows XP Windows Vista / Windows 7 ¾ Min CPU: P4 1.8 GHz ¾ Min CPU: P4 2.4 GHz ¾ Min Memory: 512MB ¾ Min Memory: 1GB (32-bits) ¾ Direct X 9 Compatible /2GB(64-bits) MAC OS X 10.4 / 10.
Chapter 10 Troubleshooting This chapter outlines possible solutions to common problems. For other issues, contact your dealer or service center. No. Problems 1 No power signal 2 No image output from the Camera 335B 3 Unable to focus 4 Cannot see the entire image Visual Presenter V2, B-WORKS and other applications cannot be used simultaneously 5 Solutions Check that the power cord is securely connected to the wall socket and the unit. 1. Check the power outlet. 2. Check the connection. Refer to 4.2.
Information in this Guide may change due to product improvements. To obtain the latest manuals, literature, and software please visit the Dukane web site at; www.dukane.com/av and look at the specific model SUPPORT or DOWNLOADS section. DUKANE CORP AV SERVICE DEPT 2900 Dukane Drive St Charles, IL 60174 800-676-2487 / 630-762-4032 Fax 630-584-5156 avservice@dukane.com www.dukane.
