2 Specification

2.1 Specification
Model DB-280
Maximum Book Size
12.6” x 15.75” ( 320mm x 400mm )
Minimum Book Size 3.15” x 1.97” ( 80mm x 50mm )
Maximum Binding Thickness 1.6” ( 40mm )
Glue Warm Up 40 minutes ( varies depending upon glue type )
Glue Warm Up in Stand-by Mode 5 minutes
Cycle Speed 360 cycles per hour
Production Speed Up to 200 books per hour
Power Source 110V, 60 Hz ( Option: 220V, 50 Hz )
Power Consumption 10 Amps.
Machine Weight 262 lbs ( 119 Kg )
Machine Dimension 49.2”(L) x 22”(W) x 18.5”(H)
(1250x560x470mm)



Model DB-200
Maximum Book Size
12.6” x 15.75” ( 320mm x 400mm )
Minimum Book Size 3.15” x 1.97” ( 80mm x 50mm )
Maximum Binding Thickness 1.6” ( 40mm )
Glue Warm Up 25 minutes ( varies depending upon glue type )
Glue Warm Up in Stand-by Mode 5 minutes
Cycle Speed 360 cycles per hour
Production Speed Up to 200 books per hour
Power Source 220V/240V, 50 Hz
Power Consumption 10 Amps.
Machine Weight 255 lbs ( 116 Kg )
Machine Dimension 45.3”(L) x 22”(W) x 14.5”(H)
(1150x560x370mm)




