MODEL/ MODÈLE/ MODELO: 9HM8000 INSERT MODEL/ MODÈLE ENCASTRABLE/ MODELO INSERTO: 9QI072ARA Español P.10 Français P.18 www.tsicustomerservice.com Twin-Star International, Inc; Delray Beach, FL 33445 Made in China • Printed in China • Fabricado en China • Impreso en China • Fabriqué en China • Imprimé en Chine REV-0 1 www.tsicustomerservice.
GETTING STARTED 1. The serial number is located on the back of the heater, the serial number is necessary for product warranty registration and customer service. Model Number SN #: 9QI072-1311M00003D MOVABLE HEATER/ MEUBLE CHAUFFANT/ CALENTADOR DE MUEBLES Date Code/ Code de Date/ Código Fecha: 9QI072ARA 120V ~, 1500W, 60Hz Twin-Star International, Inc. www.twinstarhome.com CONFORMS TO UL STD. 1278 CERTIFIED TO CSA C22.2 NO.46 EN CONFORMITÉ AVEC LA NORME UL 1278 CERTIFIÉ CSA C22.
IMPORTANT INSTRUCTIONS When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electrical shock, and injury to persons including the following: 1. Read all instructions before using this appliance. 2. This appliance is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. If provided, use handles when moving this appliance. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes and curtains at least 3 feet (0.
OPERATION INSTRUCTIONS Display Control Panel The heater can be operated by either the remote control or the control panel. Power Timer Temperature REV-0 4 www.tsicustomerservice.
OPERATION INSTRUCTIONS FUNCTION ICON POWER DESCRIPTION The POWER button supplies power to all the functions of the heater. Pressing the POWER button again the heater will be put in standby mode. Pressing and holding the POWER button on the control panel for 3 seconds will switch between °F and °C. ▲ ▼- SETTING TEMPERATURE When pressing the ▲ ▼ buttons the display will enter temperature setting mode. When in temperature setting mode pressing the ▲ ▼ buttons will change the thermostat by 1 °F (1 °C.
TROUBLESHOOTING Problem Root Cause Corrective Action Display shows “E1” The thermostat sensor is broken or disconnected. Unplug the fireplace, remove the back panel of the fireplace and check that the thermostat is plugged into the main circuit board. If this does not solve the problem contact customer service for a replacement thermostat sensor. Display shows “E2” The thermostat sensor is broken. Contact customer service for a replacement thermostat sensor.
EXPLODED VIEW Part 1 2 3 4 5 6 7 8 9 10 Part Name Control panel circuit board Infrared Element Main Circuit Board Power Cord Filter Filter Cover Blower Caster Remote Control Touch-up Pen 9 10 CARE AND MAINTENANCE • Clean the trim using a soft cloth, slightly dampened with citrus oil based product and buff with a clean soft cloth. • DO NOT use brass polish or household cleaners as these products will damage the metal trim. Citrus oil based products can be obtained at supermarkets or hardware stores.
FCC/IC INFORMATION NOTE: This equipment has been tested and found to comply with the limits for Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
3-YEAR LIMITED WARRANTY The manufacturer warrants that your new Electric Heater is free from manufacturing and material defects for a period of three years from date of puchase, subject to the following conditions and limitations. 1. Install and operate this Electric Appliance in accordance with the installation and operating instructions furnished with the product at all times. Any unauthorized repair, alteration, willful abuse, accident, or misuse of the product shall nullify this warranty. 2.
PARA EMPEZAR 1. El número de serie se encuentra en la parte posterior de la calentador, el número de serie es necesario para el registro de la garantía del producto y el servicio de atención al cliente. Número de modelo SN #: 9QI072-1311M00003D MOVABLE HEATER/ MEUBLE CHAUFFANT/ CALENTADOR DE MUEBLES Date Code/ Code de Date/ Código Fecha: 9QI072ARA 120V ~, 1500W, 60Hz Twin-Star International, Inc. www.twinstarhome.com CONFORMS TO UL STD. 1278 CERTIFIED TO CSA C22.2 NO.
INSTRUCCIONES IMPORTANTE Cuando utilice electrodomésticos, siempre tome medidas de precaución básicas para evitar incendios, descargas eléctricas y lesiones personales. Entre ellas: 1. Lea todas las instrucciones antes de usar este electrodoméstico. 2. Este calentador se calienta cuando está en uso. Para evitar quemaduras, no permita que la piel sin protección entre en contacto con superficies calientes. Si están incluidas, utilice las manijas para mover este aparato.
INSTRUCCIONES DE OPERACIÓN Pantalla Panel de control El calentador puede ser operado por el control remoto o el panel de control. Encendido Temporizador Temperatura REV-0 12 www.tsicustomerservice.
INSTRUCCIONES DE OPERACIÓN FUNCIÓN ICONO ENCENDIDO DESCRIPCIÓN El botón de ENCENDIDO (POWER) suministra energía a todas las funciones del calentador. Al presionar de nuevo el botón de ENCENDIDO (POWER) el calentador entrará en modo de espera. Mantener presionado el botón de ENCENDIDO (POWER) en el panel de control durante 3 segundos cambiará entre °F y °C. ▲ ▼- CONFIGURACIÓN DE LA TEMPERATURA Al presionar los botones ▲ ▼ la pantalla entrará en el modo de configuración de temperatura.
SOLUCIÓN DE PROBLEMAS Problema Origen de la causa Medidas correctivas La pantalla muestra “E1”. El sensor del termostato está dañado o desconectado. Desenchufe la chimenea, quite el panel posterior de la chimenea y revise que el termostato esté conectado a la placa del circuito principal. Si esto no resuelve el problema, comuníquese con atención al cliente para obtener un remplazo del sensor del termostato. La pantalla muestra “E2”. El sensor del termostato está dañado.
Los botones no funcionan Panel de control del circuito defectuoso. El pantalla no se ilumina Panel de control del circuito defectuoso Reemplace el panel de control del circuito. ¿Cuántos elementos calefactores de cuarzo hay en mi unidad? Preguntas sobre el producto 9QI 6 Elementos calefactores infra-rojos de cuarzo. No hay baterías o energía de la batería. Cambiar las baterías del control remoto. Hay una señal deficiente. Por favor opere el transmisor remoto con un ritmo lento y mesurado.
INFORMACIÓN DE FCC/IC NOTA: Este equipo ha sido probado y se ha verificado que cumple con los límites para un dispositivo digital clase B, conforme a la sección 15 de las regulaciones de la FCC. Estos límites están diseñados para proporcionar protección razonable contra interferencia perjudicial en una instalación residencial.
GARANTÍA LIMITADA DE 3 AÑO El fabricante garantiza que su nueva calentador eléctrica no presentará defectos de fabricación ni materiales durante un período de 3 año a partir de la fecha de compra, siempre y cuando se cumplan las siguientes condiciones y limitaciones. 1. Esta estufa eléctrica se debe instalar y operar en todo momento de acuerdo con las instrucciones de instalación y operación proporcionadas con el producto.
PRÉPARATION 1. Le numéro de série est situé à l’arrière du chauffage et le numéro de série est requis pour l’enregistrement de la garantie du produit et pour le service à la clientèle. Numéro de modèle SN #: 9QI072-1311M00003D MOVABLE HEATER/ MEUBLE CHAUFFANT/ CALENTADOR DE MUEBLES Date Code/ Code de Date/ Código Fecha: 9QI072ARA 120V ~, 1500W, 60Hz Twin-Star International, Inc. www.twinstarhome.com CONFORMS TO UL STD. 1278 CERTIFIED TO CSA C22.2 NO.
INSTRUCTIONS IMPORTANTES Lors de l’utilisation d’appareils électriques, pour éviter les risques d’incendie, d’électrocution et de blessures, toujours suivre les consignes de sécurité de base suivantes : 1. Lisez toutes les directives avant d’utiliser cet appareil. 2. Cet appareil est chaud lorsqu’il est en marche. Afin d’éviter les brûlures, ne touchez pas aux surfaces chaudes. Si l’appareil est muni de poignées, utilisez-les pour le déplacer.
INSTRUCTIONS D’OPÉRATION Affichage Panneau de contrôle Le chauffage peut être activé soit par la télécommande ou par le panneau de commande. Alimentation Minuterie Réglage de la température REV-0 20 www.tsicustomerservice.
INSTRUCTIONS D’OPÉRATION FONCTION ICÔNE ALIMENTATION DESCRIPTION La touche ALIMENTATION alimente toutes les fonctions du chauffage. Le fait d’appuyer à nouveau sur la touche ALIMENTATION, place le chauffage en mode veille. Appuyer sur la touche ALIMENTATION en la maintenant enfoncée sur le panneau de contrôle pendant 3 secondes permet de basculer entre °F and °C. ▲ ▼- RÉGLAGE DE LA TEMPÉRATURE Le fait d’appuyer sur les touches ▲ ▼ place l’affichage en mode de réglage de la température.
DÉPANNAGE Problème Cause probable Action corrective L’affichage indique “E1”. Le capteur du thermostat est brisé ou déconnecté. Débrancher le foyer, retirer le panneau arrière du foyer et vérifier que le thermostat est branché sur la plaquette de circuit principale. Si cela ne résout pas le problème, contacter le service à la clientèle pour demander un capteur de thermostat de rechange. L’affichage indique “E2”. Le capteur du thermostat est brisé.
Le affichage ne s’allume pas Circuit imprimé du panneau de commande défectueux. Remplacer le circuit imprimé du panneau de commande. Combien d’éléments chauffants au quartz sont présent dans l’appareil ? Renseignements sur le produit 9QI. 6 éléments chauffants infrarouges à quartz. Piles épuisées ou puissance de la batterie. Remplacer les piles de la télécommande. Signal faible. Veuillez opérer la télécommande lentement.
INFORMATION CONCERNANT FCC/IC REMARQUE : Cet appareil a été testé et déclaré conforme aux limites imposées aux appareils numériques de classe B, en vertu de l’alinéa 15 du règlement de la FCC. Ces limites sont destinées à assurer une protection raisonnable contre les interférences nuisibles dans un environnement résidentiel.
GARANTIE LIMITÉE DE 3 AN Le fabricant garantit que votre nouveau chauffage électrique est exempt de défaut de fabrication ou de matériaux durant 3 année à partir de la date d’achat, en tenant compte des conditions et des restrictions suivantes. 1. Respectez en tout temps les directives d’installation et le mode d’emploi fournis avec ce foyer électrique lorsque vous installez et que vous utilisez ce produit.
www.tsicustomerservice.com REV-0 26 www.tsicustomerservice.
