Professional Power Amplifiers more than 60 years of amplifiers experience Mobile Audio | Concert Sound | Fixed Installation | Pro Entertainment English
Contents Contents Introduction Products technical specifications Contents 02 PowerH Series 12-17 Application 54 One Brand Fits All 03 Remote Control & IRIS-Net 18 PowerH Series 55 History 04-05 RCM-26 Controller Modul 19-21 Xa 4000 56 Milestones 06-07 LX Series 22-27 LX Series 57 Manufacturing 08-09 CL Series 28-33 CL Series 58-59 Bosch Production System 10-11 SL Series 34-37 SL Series 60-61 DSA Series - Multi-Channel 38-41 DSA Series 62-65 RCM-810 Controller Mod
One Brand Fits All One Brand Fits All In our multimedia world, professional audio systems are playing an ever more important role. For this, power amplifiers are needed the characteristics and properties of which are tailored precisely to the application in question. The spectrum of these requirements—from live music to fixed installation—has an extremely wide bandwidth and extends from very high power output combined with minimum weight to remote supervision and network capability.
History German Engineering Excellence For more than 60 years, DYNACORD has been one of the most innovative and successful manufacturers of professional audio equipment.
History In 1945 Werner Pinternagel, who was an engineer, founded a workshop for the repair of radio devices in the Lower Bavarian town of Pilsting. The development and manufacture of audio amplifiers, which he began at the same time, became a particular passion. These pioneering experiences formed the foundation for over 60 years of expertise in professional power amplifier technology— expertise upon which the brand DYNACORD is able to draw today.
Milestones Milestones The constantly expanding product range yielded many pro audio milestones.
Milestones A high degree of innovation, uncompromising quality, exceptional user-friendliness and truely legendary reliability and value retention have for over 60 years defined the brand DYNACORD.
Bosch Production System 8
Bosch Production System Bosch Production System Quality with system With the introduction of the Bosch Production System (BPS) at the Straubing works, the brand DYNACORD is further enhancing its already legendary reputation for the highest production quality and reliability. Quality with system is assured by the BPS worldwide in all Bosch production centres, since absolutely identical indicators, equipment and processes are applied systematically throughout the enterprise.
Manufacturing Measurement Hall Part of the new investment involved the construction and commissioning of what at 600 square metres is one of the world’s largest audio measurement halls. Manufacturing Since September 2006, DYNACORD has belonged to the BOSCH concern’s Security Technology department. The production facility in Straubing has been considerably expanded and the work reorganized along the lines of the Bosch Production System (BPS).
Manufacturing largest audio measurement halls. One of the particular strengths of the brand DYNACORD is the fact that over the many years of its history profound know-how, covering the entire signal chain from the mixer to the loudspeakers has been acquired.
recommended applications ConcertSound, Touring, Club/Disco, ProSound, Network “All the measured data and the stability under continuous output are—as expected— of the highest order” PowerH 5000 test in `Production Partner` 10/2007 12
PowerH Series The PowerH power amp series represents a further milestone in the 60-year pro audio tradition of DYNACORD. ·· H 2500 ·· H 5000 DYNACORD has long been established worldwide as a manufacturer of professional high-performance amplifiers and by virtue of numerous innovations and the downright legendary reliability of its products has secured for itself a firm place in the elite segment.
PowerH Series PowerH Series HI-end remote controllable power amplifiers The demands placed on modern power amplifiers are enormous: maximum output, minimum weight, the highest possible degree of efficiency, outstanding audio characteristics, absolute reliability, remote supervision and remote control as well as network capability. To realize stable outputs of 2500 W / 4 Ω and 3500 W / 2 Ω per channel, power amplifiers must be capable of making available peak output voltages of 180 V to 200 V.
PowerH Series of audio performance. One of the key advantages of Grounded Bridge solutions is the considerable reduction in ‚voltage stress‘ for the power transistors. This permits the design of high-powered power amplifiers with peak output voltages in excess even of 200 V.
PowerH Series “All in all, a perfect combination, in which it is evident from every detail that the developers knew exactly what a high-end power amplifier for the professional touring and installation market needs.” PowerH 5000 test in `Production Partner` 10/2007 The power amplifiers of the PowerH series represent a milestone in the design and production of high-performance power amplifiers.
PowerH Series circuits at the output of the power amplifier are detected early on, even at low levels. The protective circuit is activated and a report on the fault in question appears simultaneously on the front display. In the event of excessive high-frequency overload, there is an automatic level reduction to protect the power amplifier itself and also the loudspeaker components connected.
Remote Control and IRIS-Net Remote Control and IRIS-Net IRIS-Net is the integrated software platform for all remote- controllable devices and systems from DYNACORD and Electro-Voice. Using IRIS-Net, complete audio systems with a large number of devices of the same or different types can be configured, supervised and controlled centrally from a single user interface. IRIS-Net supports Ethernet, CobraNet, CAN-Bus and USB as well as being open to additional future implementations.
RCM-26 RCM-26 Digital Controller Modul for Power H The RCM-26 is a dual-channel digital controller module for live sound, PA and fixed installation. It offers all conventional signal processing functions such as parametric equalizers, crossovers, delays, compressors and limiters. It also makes available linear phase FIR filters, zero-latency FIR filters and digital loudspeaker protection algorithms to permit the dynamic range of the amplifier to be exploited to the full.
RCM-26 Supervision and diagnosis The RCM-26 transmits all relevant amplifier data to the IRIS-Net user interface, supervising the operating status of the power amplifiers, the temperature in the power blocks and in the power supply, voltages and currents at the outputs, all protections, the mains voltage and current consumption, pilot tone and network status.
RCM-26 loudspeaker cabinets and systems, factory presets are available with linear phase ‚brick-wall‘ FIR crossovers. These provide users wishing to tune the system themselves with a completely linearized frequency and phase response upon which to build. system frequency response in Display For DYNACORD loudspeaker cabinets, measurements of the frequency and phase response are already provided in the IRIS-Net.
recommended applications Live Music, ConcertSound, Touring | Pro Sound Ultra Lightweight Premium Audio Performance.
LX Series LX Power Amplifiers ·· ·· ·· ·· LX 1600 LX 2200 LX 3000 XA 4000 23
LX Series LX Series ultra light weight power amplifiers LX1600 • LX2200 • LX3000 Xa 4000 • • • • • • • • • high-efficiency Class-H design switching power supply extremely light and compact 30% dynamic headroom very high 2 ohm stability complete package of protective circuits dynamic audio limiter precise raster pots on front panel constant gain with 32dB SWITCHING POWER SUPPLY TECHNOLOGY The combination of an analogue class-H design with a state-ofthe-art switching power supply has made possible the
LX Series 25
LX Series Were they to appear in a high-end hi-fi magazine, the measured values of the LX1600 would no doubt have the audiophiles drooling. From every single discipline it’s evident that the people working in Dynacord’s development department in Straubing are perfectionists in the best sense of the word.
LX Series LX 1600 With an output rated at 2 x 1300 watts into 2 ohms and 2 x 800 watts into 4 ohms, this is the ideal power amplifier for small to medium-sized full-range cabinets and MF/HF components in active multi-way systems. LX 2200 With a stable output of 2 x 1600 watts into 2 ohms and 2 x 1100 watts into 4 ohms, this is the ideal amplifier for professional multi-way components as well as medium-sized subwoofers in concert sound systems.
recommended applications Live Music | Concert Sound, Club/Disco, Commercial Superior Audio Performance, highest reliability and operational safety.
CL Series Power Amplifiers ·· ·· ·· ·· CL CL CL CL 800 1200 1600 2000 29
CL Series 30
CL Series CL Series Thoroughbred workhorses for the most demanding audio tasks TECHNOLOGY Through the use of optimized power supplies with toroidal transformers (on account of their low stray fields) and the intelligent application of class H technology (CL 800: class AB), headroom way above the declared nominal power has been achieved as well as a notable reduction in weight and waste heat.
CL Series FRONT PANEL The dB-calibrated level controls are implemented as ultra-precise detent potentiometers that are recessed in the front panel to protect them from accidental contact. Power, Protect, Signal and Limit LEDs provide a quick overview of the operating status. REAR PANEL The electronically balanced XLR IN / OUT sockets are provided for direct operation with professional mixing consoles and signal processors. All the models in the CL series are designed for a Constant Gain of 32 dB.
CL Series LPN + LO-CUT The retrofittable NRS 90268 kit, which is available as an option for all CL power amplifiers, combines the patented LPN (low-pass notch) filter with a low-cut filter. +15 +10 +5 % These eliminate transient non-linearity in the low frequency range in small to medium-sized full-range speakers and thereby considerably extend the reproducible range at the bottom end. The acoustic result is bass reproduction with more punch and greater substance.
recommended applications Live Music | Concert Sound, Commercial Stable power output and a high efficiency factor on the high performance level.
SL Series SL Power Amplifiers ·· ·· ·· ·· SL SL SL SL 900 1200 1800 2400 35
SL Series Solid DYNACORD technology for universal application at highly competitive prices was the maxims for the development of the SL series of power amplifiers. They offer high, stable power output and a high efficiency factor on the high performance level and are therefore the ideal choice for driving a multitude of mobile and club systems, such as e.g. loudspeakers of the D-Lite, VariLine or Forum Line families.
SL Series SL Series Solid all-rounders at a competitive price The level controls on the front are calibrated in dB and recessed into the front panel to guard against mechanical damage. The easy-to-read LED display with its Power, Protect, Signal and Limit indicators offers a quick overview of the operating state of the power amplifiers. +12 +9 +6 transient behaviour of loudspeakers.
recommended applications Multi Media, Club/Disco, Pro Sound, Commercial | Network Universal installation power amplifiers with optional network capability (IRIS-Net).
DSA Series DSA Power Amplifiers ·· ·· ·· ·· ·· ·· ·· DSA DSA DSA DSA DSA DSA DSA 8405 8410 8805 8204 8206 8209 8212 39
DSA Series - Multi-Channel DSA Series - Multi-Channel can drive any load between 2 and 10 ohms with their rated maximum outputs of 500 W and 1000 W respectively per channel or directly drive 70 Vrms or 100 Vrms loudspeaker lines.
DSA Series - Multi-Channel Depending upon the application, each channel can be switched individually even in high-impedance mode (HZ) in order to drive 70 Vrms or 100 Vrms loudspeaker lines directly without an output transformer (Direct Drive).
RCM-810 42
RCM-810 RCM-810 digital controller module The RCM-810 remote control module is a digital controller module for PA and fixed installation and permits the integration of DSA amplifiers in a remote control network with up to 250 devices. With it, a complete PA system can be controlled and supervised from one or several PCs with the help of IRIS-Net software. Data on all operating states – e.g. switch-on status, temperature, response of protective circuits, load impedance etc.
DSA Series - Dual-Channel 44
DSA Series - Dual-Channel DSA Series - Dual-Channel amplifiers that provide a multitude of highly economic solutions to the problems posed by fixed installations. Solid DYNACORD technology for fixed installations at very competitive prices was the maxims for the development of the DSA power amplifier series. They offer a very high, stable output with high efficiency at a high performance level. DSA power amplifiers are therefore the ideal choice for typical fixed installation applications.
recommended applications Commercial Power amplifiers for challenging sound reinforcement.
PCL Series PCL Series ·· ·· ·· ·· ·· PCL PCL PCL PCL PCL 1125T 1225T 1240T 1245 1415 47
PCL Series PCL Series contractor line power amplifiers With the PCL series, DYNACORD is adding to its extensive power amplifier range in the fixed installation segment a number of models with fairly low to medium output levels. The power amplifiers are particularly designed for challenging sound reinforcement tasks, background music / paging and public address system installations. Long term reliability, operational safety, flexibility and versatility are guaranteed.
PCL Series Features • five models from 160 W to 450 W per channel; 4 ohm or 50 / 70 / 100 V • compact 2U housing • Phoenix input plugs for simple setting-up • single block plug for all output signals • bridged mode for all multi-channel models • switchable high-pass filter in each channel; 50 Hz or 300 Hz • level controller for each channel on the rear panel • front-to-rear cooling • numerous protective circuits 49
recommended applications Network, Live Safety | ProSound | Multi Media, Commercial Fixed installation power amplifiers with emergency power capability and IRIS-Net integration.
DPA Series DPA Series ·· ·· ·· ·· ·· ·· ·· ·· ·· DPA DPA DPA DPA DPA DPA DPA DPA DPA 4120 4140 4410 4411 4245 4260 8150 8225 8412 51
DPA Series DPA Series FINEST AUDIO QUALITY FOR ALARM SOUND REINFORCEMENT Power amplifiers of the highest quality and legendary reliability have for decades been a core element of the DYNACORD fixed installation range.
DPA Series The new models of the DPA 8000 series are based on highly efficient Class D platforms and offer in addition to outstanding audio performance features such as integrated automatic breakdown switchover, integrated electronics for the connection of multiple loudspeaker lines per amplifier channel, an additional audio input, etc. The Promatrix 8000 system, to which the DPA 8000 amplifiers also belong, sets new standards in the integration of event, information and evacuation sound reinforcement.
Recommended Products / Application Recommended Products / Application RECOMMENDED PRODUCTS / APPLICATION Mobile Audio Live Music Concert Sound Fixed Installation Touring Multi Media Boardrooms Large Live Corporate Club-Gigs Productions Conferencing Rental Dance Bands Hotels Mobile DJ Top 40 Events Small - Medium Festival Club/Disco ProSound Network Commercial Life Safety Clubs Lounges Discotheques Poolbars Casinos Theaters Concert Halls HOW Stadiums Cruise LIners Multifunctional Halls Confer
PowerH Series PowerH 5000 PowerH Series technical specifications General H 2500 2Ω Load Impedance H 5000 4Ω 8Ω 2Ω 4Ω 8Ω Maximum Midband Output Power, 1 kHz, THD=1% 2000 W 1450 W 850 W 3500 W 2500 W 1500 W Rated Output Power, 20 Hz ... 20 kHz, THD <0.1% - 1200 W 600 W - 2100 W 1050 W Max. Single Channel Output Power Dynamic-Headroom, IHF-A 2400 W 1700 W 940 W 4500 W 3200 W 1800 W Max.
Xa 4000 Xa 4000 technical specifications General Load Impedance Maximum Midband Output Power, THD=1%, 80Hz SUB, 1 kHz TOP, Single Channel Rated Output Power, THD <0.1%, 20 Hz-140 Hz SUB, 140 Hz-20 kHz TOP Single Channel Maximum RMS Voltage Swing, THD=1%, 80 Hz SUB, 1 kHz TOP Power Bandwidth, THD=1%, ref. 1kHz, half power @ 4Ω Voltage Gain ref. 1 kHz Input Sensitivity at rated output power, 1 kHz THD at rated output power, MBW=80kHz, 1 kHz Max.
LX Series LX 2200 LX Series technical specifications General LX 1600 LX 2200 LX 3000 2Ω 4Ω 8Ω 2Ω 4Ω 8Ω 2Ω 4Ω 8Ω 1300 W 800 W 500 W 1600 W 1100 W 600 W 2100 W 1500 W 900 W - 700 W 350 W - 900 W 450 W - 1200 W 600 W Max. Single Channel Output Power Dynamic-Headroom, IHF-A 2200 W 1200 W 625 W 2600 W 1400 W 720 W 2900 W 1800 W 1000 W Max.
CL Series CL Series technical specifications General Load Impedance CL 800 2Ω CL 1200 4Ω 8Ω 2Ω 4Ω 8Ω Maximum Midband Output Power, 1 kHz, THD=1% 600 W 400 W 240 W 900 W 600 W 350 W Rated Output Power, 20 Hz ... 20 kHz, THD <0.1% - 300 W 150 W - 500 W 250 W Max. Single Channel Output Power Dynamic-Headroom, IHF-A 1100 W 580 W 300 W 1450 W 850 W 450 W Max.
CL Series CL 1600 General CL 1600 CL 2000 2Ω 4Ω 8Ω 2Ω 4Ω Maximum Midband Output Power, 1 kHz, THD=1% 1100 W 800 W 500 W 1500 W 1000 W 600 W Rated Output Power, 20 Hz ... 20 kHz, THD <0.1% - 700 W 350 W - 850 W 450 W Max. Single Channel Output Power Dynamic-Headroom, IHF-A 2200 W 1200 W 625 W 2700 W 1450 W 750 W Max.
SL Series SL Series technical specifications General SL 900 SL 1200 2Ω 4Ω 8Ω 2Ω 4Ω 8Ω 650 W 450 W 270 W 900 W 600 W 380 W - 400 W 200 W - 500 W 250 W Max. Single Channel Output Power Dynamic-Headroom, IHF-A 1150 W 660 W 350 W 1700 W 950 W 480 W Max. Single Channel Output Power Continuous, 1kHz 850 W 540 W 310 W 1200 W 750 W 420 W 1300 W 900 W - 1800 W 1200 W Load Impedance Maximum Midband Output Power, 1 kHz, THD=1%, Dual Channel Rated Output Power, 20 Hz ...
SL Series SL 1200 General SL 1800 SL 2400 2Ω 4Ω 8Ω 2Ω 4Ω 8Ω 1250 W 900 W 550 W 1800 W 1200 W 750 W - 800 W 400 W - 1100 W 550 W Max. Single Channel Output Power Dynamic-Headroom, IHF-A 2450 W 1400 W 700 W 3400 W 1800 W 950 W Max. Single Channel Output Power Continuous, 1kHz 1700 W 1100 W 630 W 2400 W 1500 W 850 W 2800 W 1800 W - 3600 W 2400 W Load Impedance Maximum Midband Output Power, 1 kHz, THD=1%, Dual Channel Rated Output Power, 20 Hz ... 20 kHz, THD <0.
DSA Series - Multi-Channel DSA Series - Multi-Channel technical specifications General DSA 8405 DSA 8805 2Ω 4Ω 8Ω 70 V / 10Ω 100 V / 20Ω 2Ω 4Ω 8Ω 70 V / 10Ω 100 V / 20Ω Maximum Midband Output Power, 1 kHz, THD=1%, 4 channels driven 500 W 500 W 250 W VLD:500 W 500 W 500 W 500 W 500 W 250 W VLD:500 W 500 W 500 W Rated Output Power, 20 Hz ... 20 kHz, THD <0.
DSA Series - Multi-Channel DSA 8805 General DSA 8410 2Ω 4Ω 8Ω 70 V / 5Ω 100 V / 10Ω Maximum Midband Output Power, 1 kHz, THD=1%, 4 channels driven 1000 W 1000 W 500 W VLD:1000 W 1000 W 1000 W Rated Output Power, 20 Hz ... 20 kHz, THD <0.
DSA Series - Dual-Channel DSA Series - Dual-Channel technical specifications General DSA 8204 DSA 8206 2Ω 4Ω 8Ω 2Ω 4Ω 8Ω 650 W 450 W 270 W 900 W 600 W 380 W - 400 W 200 W - 500 W 250 W Max. Single Channel Output Power Dynamic-Headroom, IHF-A 1150 W 660 W 350 W 1700 W 950 W 480 W Max.
DSA Series - Dual-Channel DSA 8212 General DSA 8209 DSA 8212 2Ω 4Ω 8Ω 2Ω 4Ω 8Ω 1250 W 900 W 550 W 1800 W 1200 W 750 W - 800 W 400 W - 1100 W 550 W Max. Single Channel Output Power Dynamic-Headroom, IHF-A 2450 W 1400 W 700 W 3400 W 1800 W 950 W Max. Single Channel Output Power Continuous, 1kHz 1700 W 1100 W 630 W 2400 W 1500 W 850 W - 2800 W 1800 W - 3600 W 2400 W Load Impedance Maximum Midband Output Power, 1 kHz, THD=1%, Dual Channel Rated Output Power, 20 Hz ...
PCL Series PCL Series technical specifications PCL 1125T General PCL 1415 PCL 1245 PCL 1240T 8Ω 4Ω 8Ω 4Ω 8Ω 4Ω Max. Midband Output (THD < 0.2 %, 20 Hz…20 kHz) 100 W 160 W 300 W 480 W 215 W 430 W 430 W Rated Output Power (THD < 0.2 %, 20 Hz…20 kHz) 75 W 150 W 225 W 450 W 200 W 400 W 400W Load Impedance 100 V 70 V 50 V 4 2 Max. RMS Voltage Swing (THD = 1 %, 1 kHz) 32.1 V 44.7 V 44.7 V 117 V 82 V 59 V Voltage Gain (at 1 kHz) 30 dB 34.3 dB 34.3 dB 42.2 dB 39.
PCL Series PCL 1415 General PCL 1225T 8Ω 4Ω Max. Midband Output (THD < 0.2 %, 20 Hz…20 kHz) 135 W 270 W Rated Output Power (THD < 0.2 %, 20 Hz…20 kHz) 125 W 250 W Load Impedance 100 V PCL 1125T 70 V 50 V 100 V 270 W 250 W 40 Ω 50 V 270 W 250 W 19.6 Ω 250 W 10 Ω 250 W 40 Ω 250 W 19.6 Ω 2 Channels 70 V 250 W 40 Ω 1 Max. RMS Voltage Swing (THD = 1 %, 1 kHz) 35.4 V 117 V 82 V 59 V 117 V 82 V 59 V Voltage Gain (at 1 kHz) 32.2 dB 42.2 dB 39.1 dB 36.2 dB 42.2 dB 39.
DPA 4000 Series DPA 4000 Series technical specifications General Load Impedance Rated Output Power (Mains) DPA 4410 DPA 4120 DPA 4140 100 Ω / 100 V, 50 Ω / 70 V 25 Ω / 50 V, 4 Ω / 20 V DPA 4411 50 Ω / 100 V, 25 Ω / 70 V 12.5 Ω / 50 V, 4 Ω / 28 V 25 Ω / 100 V, 12.5 Ω / 70 V 6.25 Ω / 50 V, 4 Ω / 40 V 4 x 100 W (acc. to IEC 268-3 / 19.4) 2 x 200 W configurable 1 x 200 W + 2 x 100 W configurable 200 W (acc. to IEC 268-3 / 19.4) 400 W (acc. to IEC 268-3 / 19.
DPA 4000 Series DPA 4411 General Load Impedance Rated Output Power Maximum Output Power Output Power in Bridged-Operation DPA 4245 DPA 4260 28.5 Ω / 100V 20 Ω / 100V 14 Ω / 70 V 9.8 Ω / 70 V 1.8 Ω / 25 V 1.25 Ω / 25 V 4 Ω / 37.4 V 4 Ω / 44.7 V 350 W (acc. to IEC 268-3 / 19.4) 500 W (acc. to IEC 268-3 / 19.4) 450 W into 4 Ω 600 W into 4 Ω 700 W (acc. to IEC 268-3) 1000 W (acc.
DPA 8000 Series DPA 8000 Series technical specifications General Load Impedance DPA 8150 50 V / 5 Ω 50 V 70 V 30.2 dB 33.1 dB THD at rated output power MBW=80kHz, 1kHz < 0.5 % IMD-SMPTE, 60Hz, 7kHz < 2.0 % DIM 30, 3,15kHz, 15kHz Max. Input Level < 0.2 % < -80 dB Frequency Response, ref. 1 kHz, rated load 50 Hz...
DPA 8000 Series DPA 8412 General Load Impedance DPA 8225 50 V / 10 Ω 70 V / 19.6 Ω 50 V 50 V / 20 Ω 70 V 100 V 50 V 30.2 dB 33.1 dB 36.2 dB < 2.0 % DIM 30, 3,15kHz, 15kHz < 0.2 % 30.2 dB 36.2 dB < 1.0 % < 0.1 % Crosstalk, ref. 1 kHz at rated output power < -80 dB Frequency Response, ref. 1 kHz, rated load 50 Hz...
