Air Brake and EEC Kit Installation Guide for 200i/250i and 200iP/250iP Motorcycle Dynamometers
AIR BRAKE AND EEC KIT
Replacing Pit Cover Plates and Upright Brace—200iP/250iP
34
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
REPLACING PIT COVER PLATES AND UPRIGHT BRACE—200IP/250IP
Refer to “Replacing the Drum Module Hood, Side Drum Cover, Center Panel, and Tire
Carriage—200i/250i” on page 33 for model 200i/250i dynos.
1 Secure the upright brace to the drum module using the two screws removed
earlier. Refer to Figure 7 on page 9.
2 Secure the right pit cover plate to the dyno using the eight
1/4-20 x 5/8-inch pan head screws removed earlier. Refer to Figure 26 on page 26.
3 Secure the right drum guard to the drum guard mount using the two
1/4-20 x 5/8-inch pan head screws removed earlier. Refer to Figure 27 on page 27.
Do not operate the dynamometer without the EEC finger guards properly
installed. The gap between the finger guards and the drum must be less than
0.64 centimeters (0.25 inches). Refer to page 28 for instructions on adjusting
the gap.
