Air Brake and EEC Kit Installation Guide for 200i/250i and 200iP/250iP Motorcycle Dynamometers
AIR BRAKE AND EEC KIT
Air Brake
8
4 Remove the four 1/4-20 x 5/8-inch pan head screws and the four 3/8-16 x 1/2-inch
screws securing the right pit cover plate to the dyno chassis and set aside.
5 Remove the right pit cover plate and set aside.
Figure 6: Removing the Right Pit Cover Plate
screw
right pit cover plate
