Above Ground Model 424x/424xLC
2
Automotive Dynamometer Installation Guide
CHAPTER 4
Torque Module Installation
4-16
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TORQUE MODULE INSTALLATION
This section describes how to install the Torque Module(s), connect the load cell
cable, and install the side and top brake covers.
INSTALLING THE TORQUE MODULE
You will need the following part:
• 66104001 Torque Module
1 Verify the main dyno power is disconnected.
2 Turn off the main power switch on the CPU Module and unplug the power cord.
3 Remove the dust cover from the existing top module.
Figure 4-18: Disconnect Power and Remove the Dust Cover
HS039
dust cover
power cord
input
power switch
