4WD DYNO INSTALLATION
Cable Routing
Version 8 Above Ground Model 424x/424xLC
2
Automotive Dynamometer Installation Guide
3-13
Figure 3-7: Routing the Cables—Without the Eddy Current Brakes
AD371
DRY AIR IN
100-140 PSI
E
C
D
dyno
electronics
stationary dyno
4WD dyno
first cable
track
F
power supply
dyno movement
pendant
power supply for
dyno electronics
Breakout
board
second
cable track
A
G
I
B
H
