4WD DYNO INSTALLATION
Hydraulic Movement Installation
Version 8 Above Ground Model 424x/424xLC
2
Automotive Dynamometer Installation Guide
3-25
2 Secure the hydraulic ram to the dyno cylinder mount using one clevis pin and
hairpin cotter.
Figure 3-15: Secure the Hydraulic Ram to the Dyno Cylinder Mount
AD343
clevis pin
hairpin cotter
dyno cylinder mount
hydraulic ram
