Automotive Dynamometer Installation Guide
CHAPTER 3
Hydraulic Movement Installation
3-26
3 Temporarily hold the floor cylinder mount to the hydraulic ram using two spacers
and one clevis pin.
Figure 3-16: Hold the Floor Cylinder Mount to the Ram
AD485
clevis pin
spacers
floor cylinder
mount
hydraulic ram
