4WD DYNO INSTALLATION
Hydraulic Movement Installation
Version 8 Above Ground Model 424x/424xLC
2
Automotive Dynamometer Installation Guide
3-31
FILLING THE HYDRAULIC MOTOR WITH HYDRAULIC FLUID
1 Remove the cap on the hydraulic motor.
2 Add four quarts of AW-68 hydraulic fluid.
3 Replace the cap.
Figure 3-21: Fill the Hydraulic Motor with Oil
AD488
remove the cap on
the hydraulic motor
