Operating manual HP04 04.10.
Contents Getting started 4 5 7 8 8 9 10 12 13 14 15 16 17 Registration Important safety instructions Assembly Controls Continuous monitoring Connecting to the Dyson Link app Information menu Auto mode Heating Oscillation Airflow Sleep timer Night mode 17 18 2 04.10.
Thank you for choosing to buy a Dyson purifying fan heater Take full control with the Dyson Link app Download the Dyson Link app Download the Dyson Link app from the App Store or Google Play. Open the app and follow the on-screen instructions to create a new account. Get step-by-step setup and support. Control how and when your purifying fan heater runs. Monitor and record air quality through visual updates. Automatically keep up to date with the latest software upgrades.
Registration After registering your 2 year guarantee, your Dyson appliance will be covered for parts and labour (excluding filters) for 2 years from the date of purchase, subject to the terms of the Dyson guarantee. Your serial number can be found on your rating plate which is on the base of the appliance. 4 easy ways to register your 2 year guarantee Register with your smartphone Download the Dyson Link app and you will be taken through registration as part of the set up.
IMPORTANT INSTRUCTIONS WARNING THE APPLIANCE AND THE REMOTE CONTROL BOTH CONTAIN MAGNETS. 1. Pacemakers and defibrillators may be affected by strong magnetic fields. If you or someone in your household has a pacemaker or defibrillator, avoid placing the remote control in a pocket or near to the device. 2. Credit cards and electronic storage media may also be affected by magnets and should be kept away from the remote control and the top of the appliance.
12. Do not use outdoors or on wet surfaces and do not handle any part of the appliance or plug with wet hands. 13. Keep the appliance away from flammable liquids, vapours, air fresheners and essential oils. 14. Always plug directly into a wall socket. Never use with an extension cable as overloading may result in the cable overheating and catching fire. 15. Do not use this appliance if it has been damaged or submerged in water. 16.
Assembly Use both hands to lift the appliance out of the box, taking care to hold by the base of the appliance only. Do not lift out by the amplifier loop. Slide the buttons down on both sides of the shrouds. The shrouds will release with the glass HEPA filters attached. Take the carbon filters out of the box and remove the protective packaging. Position the shrouds onto the base and push gently until they click securely into place. Attach both carbon filters to the appliance.
Controls Continuous monitoring Remote control Standby ON/OFF Standby ON/OFF Information menu Airflow speed Heating control Auto mode Fan mode Oscillation ON/OFF Airflow direction Sleep timer Night mode With continuous monitoring enabled, your appliance will gather air quality, temperature and humidity information, which is displayed on the LCD screen and in the Dyson Link app. By default, continuous monitoring is disabled. Once enabled, continuous monitoring is always active.
Connecting to the Dyson Link app The Dyson Link app allows you to control, schedule, monitor, and customise your settings for your appliance from your mobile device. Wi-Fi is enabled by default. To disable or enable the Wi-Fi press and hold the ON/OFF button on the appliance for 5 Seconds. Plug in your appliance to the mains electricity supply and turn on the power. Check your mobile device is compatible with the app, switched on, connected to a Wi-Fi network and Bluetooth® wireless technology enabled.
Information menu Press this button to scroll through the information being monitored by your appliance. Information about air quality, temperature, humidity and filter levels are shown. When a pollutant causes the air quality to drop, the relevant symbol will show on the LCD screen. 10 04.10.
Indoor air quality - 12 seconds Monitors the current air quality with a graph showing the last 12 seconds of data. Indoor air quality - 24 hours Monitors the air quality with a graph showing 24 hours of data, sampled at five-minute intervals. Particulate matter (PM2.5) Monitors the presence of microscopic particles up to 2.5 microns in size, suspended in the air we breathe. These include smoke, bacteria and allergens.
Auto mode Set your appliance to Auto mode and the on-board sensors will intelligently adjust the settings of the appliance according to the air quality. Air quality: Your appliance will pause when the target air quality has been reached, switching on again when the air quality levels drop. Airflow speed: The airflow speed will increase until the target air quality and temperature have been reached. Night mode: Your appliance will only run with airflow speeds from 1 to 4. 12 04.10.
Heating Press the button to set the required room temperature. Your appliance will pause when the temperature set has been reached. Press the Fan mode button to switch your appliance from Heating mode to Fan mode. 1-10 Target temperature Current room temperature Fan mode 13 04.10.
Oscillation Press the button to circulate the air around the room and scroll through the oscillation settings from 0° to 350°. Customise your oscillation settings in the Dyson Link app. 14 04.10.
Airflow Press the Airflow speed button to increase and decrease the airflow speed. Press the Airflow direction button to change the direction of airflow from front to back. Your appliance will continue to purify in both settings. Heating mode will only function when the air direction is set to the front. If airflow is changed to the back, your appliance will change to Fan mode. 1-10 15 04.10.
Sleep timer Your appliance will turn off automatically after the selected amount of time. To set the time: Press the button to scroll through the time options. Once activated press the Sleep timer button once to see the time selected. To cancel the Sleep timer: Press the Sleep timer button twice. 16 04.10.
Night mode Care and maintenance In Night mode, your appliance will continue to monitor and respond to changes in air quality and temperature, but only using its quietest settings – and with its LCD screen dimmed. To always get the best performance from your appliance, it is important to regularly clean it and check for blockages. 1-4 AUTO mode 1-10 Manual Changing your filters: The display on your appliance and app will indicate when to change your filters.
Additional information CONTROL WITHOUT THE REMOTE • The appliance can be controlled through your Dyson Link app. DYSON LINK APP CONNECTIVITY • You must have a live Internet connection in order for the Dyson Link app to work. • The appliance can connect to either 2.4GHz or 5GHz networks which includes most modern routers. Check your router documentation for compatibility. • The Dyson Link app requires an iOS device with at least iOS version 10* or an Android device with at least Android version 5.
• Dispose of the exhausted filter units in accordance with local ordinances or regulations. • The battery should be removed from the product before disposal. DYSON CUSTOMER CARE THANK YOU FOR CHOOSING TO BUY A DYSON APPLIANCE After registering your 2 year Dyson guarantee, your Dyson appliance will be covered for parts and labour for 2 years from the date of purchase, subject to the terms of the guarantee.
NEW ZEALAND CONSUMER LAW Under the New Zealand Consumer Guarantees Act 1993, if the product is not of acceptable quality but that defect is not substantial, Dyson may choose whether to repair or replace the product. If a repair will be difficult, Dyson may instead provide you with a refund. If a product’s defect is substantial or cannot be fixed, you can ask for either a refund, replacement product, or compensation for any reduction in that product’s value.
04.10.
www.dyson.co.nz 04.10.2018 15:07 - C97193-DYS_OPMAN_ANZ_X527-PURE-HOT+COOL-OPMAN_15_4c0s JN.97193 PN.270731-09-02 04.10.18 www.dyson.com.
email Mobile Telephone Store of purchase Privacy statement Dyson Appliances Ltd (Dyson) may collect and use your personal information to provide you updates on latest products and services, to analyze and research customer’s choice on products, to provide products and services you have requested and for other purposes relating or incidental to warranty (e.g. warranty registration, product recalls) (“the Purposes”).
Guarantee form Date of purchase / / Country of purchase Serial number Title Surname First name Address Postcode 04.10.
