Super Cub 25e ARF Assembly Manual
Notice All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, Inc. For up-to-date product literature, visit http://www.horizonhobby. com and click on the support tab for this product.
Table of Contents Introduction............................................................... 3 Important Information Regarding Warranty Information........................................ 3 Specifications............................................................ 3 Using the Manual...................................................... 3 Contents of Kit/Parts Layout....................................... 4 Covering Colors......................................................... 4 Hardware/Accessory Sizes..
Contents of Kit/Parts Layout Replacement Parts EFL460001 EFL460002 EFL460003 EFL460004 EFL460005 EFL460006 EFL460007 EFL460008 EFL460009 EFL460010 EFL460011 EFL460012 EFL460013 EFL460014 EFL460015 EFL460016 EFL460017 EFL460019 EFL460020 Wing Set Fuselage Tail Set Rudder Cowling Windshield Top Window Window Set Wing Tube Wheel Set Tail Wheel Pushrod Set Seat Set Strut Set Accessory Set Landing Gear Hardware Set Fuselage Hatch Servo Hatch Covering Colors White True Red 4 HANU870 HANU866 Hardware/Accessor
Before Starting Assembly We recommend installing the lighting kit and interior in the sequence of steps shown in the manual. Adding these items after the model is built may not be possible without causing damage to your airframe. Please decide prior to beginning construction whether or not you would like to incorporate these items in your airplane.
2. Locate three hinges for the flaps. Use side cutters 4. Fit the hinge and flap to the wing. Position the to trim one end of each hinge to 11/16-inch flap so it aligns with the wing and that the hinge (17mm). The trimmed end will be placed in the flap. line is equal along the entire length of the flap. 3. Insert the trimmed end of the hinges into the flap. Check that the hinge moves perpendicular to the hinge line.
8. Use a small amount of low-tack tape to hold the flap in position until the epoxy fully cures. Use a paper towel and isopropyl alcohol to remove any excess epoxy before it cures. 9. Repeat steps 1 through 8 to install the remaining flap. 11. Place a T-pin in the center of each of the four hinges. This will center the hinges equally in the aileron and wing when they are installed. 12. Insert the hinges in the ailerons. The T-pin will rest on the edge of the aileron bevel. 13.
15. Saturate each hinge with thin CA. Apply CA to both the top and bottom of the hinge. 16. Once the CA has cured, gently pull on the control surface and wing to make sure the hinges are glued securely. If not, apply CA to those hinges that are not glued and recheck. 8 17. Move the control surface through its range of motion several times to break in the hinges. This will reduce the initial load on the servo during your first flights. 18.
2. Prepare the servo by installing the servo grommets and brass eyelets. 3. Use a #1 Phillips screwdriver to thread a servo mounting screw into each of the holes to cut threads in the surrounding wood. Remove the screw before moving to the next step. 4. Apply 2–3 drops of thin CA in each of the holes to harden the surrounding wood. This will harden the threads so the screws do not easily strip the surrounding wood. 5.
9. Connect a 6-inch (152mm) servo extension to the servo lead. Use a string or piece of dental floss to secure the leads so they do not accidentally disconnect inside the wing. 10. A string is located in the wing to pull the servo lead through the wing. Tie the string to the end of the servo lead as shown. 10 11. Remove the flap servo cover and use the string to pull the aileron extension through the area of the hatch for the flap servo. 12.
15. Use a #1 Phillips screwdriver to thread a 2mm x 8mm self-tapping screw into each of the predrilled holes to cut threads in the surrounding wood. Remove the screw before moving to the next step. 17. Remove the control horn backplate from the control horn using a hobby knife and #11 blade. The backplate can be discarded as it is not used in the assembly of your model. 16. Apply 2–3 drops of thin CA in each of the holes to harden the surrounding wood.
24. Next, set the full-flap position Use the travel adjustment to set the down flap position as shown. Aileron and Flap Attach clevis to the outer hole 27. Use canopy glue to attach the scale aileron linkage cover to the top of the wing. Position the cover so it is centered along the width of the aileron. The cover will rest 3/4-inch (19mm) forward of the hinge line as shown. Use low-tack tape to hold the cover in position until the glue fully cures. Install both covers at this time.
Motor and Speed Control Installation Required Parts Fuselage Motor with hardware 4-40 x 3/4-inch socket head cap screw (4) Aluminum spacer, 3/8-inch (9.5mm) (4) Speed control Servo extension, 9-inch (228mm) Always use threadlock on metal-to-metal fasteners to prevent them from vibrating loose. Required Tools and Adhesives Threadlock Phillips screwdriver: #1 Dental floss Hex wrench: 3/32-inch 3. Remove the battery hatch by lifting it at the rear.
5. Place the speed control in the fuselage. Use twosided tape to secure the speed control in the fuselage so it rests against the landing gear mount. Cowling, Propeller and Flight Battery Installation 7. Mount the switch in the fuselage using the hardware provided with the speed control. Required Parts Fuselage assembly Cowl Propeller Spinner assembly (not included) Motor battery Hook and loop strap Hook and loop tape Required Tools and Adhesives Box wrench: 10mm Hex wrench: 3/32-inch 14 6.
Landing Gear Installation Always balance your propeller. An unbalanced propeller can cause vibrations to be transmitted into the airframe, which could damage the airframe or other components as well as produce unwanted flight characteristics. We recommend using the optional spinner to enhance the looks of your model. 2. Slide the propeller/spinner on the motor shaft. Use a 10mm box wrench to tighten the nut securing the assembly to the motor shaft. 4.
16 1. Place the wing strut tabs between the rear landing gear mounts and fuselage. Make sure the angle on the tab faces toward the top of the fuselage. Secure the four landing gear mounts and the two wing strut tabs to the fuselage using eight 6-32 x 1/2-inch socket head cap screws and a 1/8-inch hex wrench. Leave the screws loose so the mounts can be positioned when installing the landing gear legs. 2.
Always use threadlock on metal-to-metal fasteners to prevent them from vibrating loose. 7. Use a 1.5mm hex wrench to tighten the setscrew securing the 5/32-inch wheel collar to the flat on one end of the axle. 9. Press the outer hub into the tire, aligning the holes in the outer hub with those in the inner hub. Use a #1 Phillips screwdriver to install the four 2mm x 15mm self-tapping screws that secure the hubs together.
Stabilizer and Tail Bracing Installation Required Parts Fuselage assembly Stabilizer (right and left) 2-56 x 61/2-inch threaded rod (2) 2-56 x 63/4-inch threaded rod (2) 4-40 x 5/8-inch socket head cap screw (3) 4-40 x 1/4-inch socket head cap screw (2) 4-40 lock nut (3) Nylon brace end (8) Carbon rod, 51/8-inch (130mm) Carbon rod, 39/16-inch (90mm) 2. Slide the stabilizer into position, guiding the carbon rods through the holes in the fuselage. Slide the stabilizer so it is tight against the fuselage.
5. Use a pin vise and 7/64-inch (3mm) drill bit to enlarge the hole in the eight nylon brace ends. 7. Attach the nylon ends to the stabilizer using two 4-40 x 5/8-inch socket head cap screws and two 4-40 lock nuts. Use a 3/32-inch hex wrench and 1/4-inch nut driver to tighten the hardware. Leave the hardware slightly loose so the rods can be positioned. When installing the rods, make sure they are in tension with one another slightly. This is what gives the tail bracing its strength.
9. The upper rods are attached to the fin using a 4-40 x 5/8-inch socket head cap screw and 4-40 locknut. Thread the nylon ends in or out as necessary to set the length of the rods. Use a square to check that the stabilizer remains square to the fin on both the top and bottom of the fuselage. Elevator Installation Required Parts Fuselage assembly CA hinge (6) Elevator (2) Control horn (2) 2mm x 8mm self-tapping screw (4) 2.
4. Apply 2–3 drops of thin CA in each of the holes to harden the surrounding wood. This will harden the threads so the screws do not easily strip the surrounding wood. 5. Install the control horn using two 2mm x 8mm self-tapping screws and a #1 Phillips screwdriver. E-flite Super Cub 25e ARF Assembly Manual 6. Place a T-pin in the center of each of the three hinges. This will center the hinges equally in the elevator and stabilizer when they are installed. 8.
10. Saturate each hinge with thin CA. Apply CA to both the top and bottom of the hinge. 12. Move the control surface through its range of motion several times to break in the hinges. This will reduce the initial load on the servo during your first flights.
A . If you are installing the lighting kit, make sure to remove the covering from the tube in the rudder using a hobby knife and #11 blade. 2. Use a #1 Phillips screwdriver to thread a 2mm x 8mm self-tapping screw into each of the pre-drilled holes to cut threads in the surrounding wood. Remove the screw before moving to the next step. 4. Remove the control horn backplate from the control horn using a hobby knife and #11 blade.
6. Attach the rudder tiller arms using a 2mm x 12mm machine screw and 2mm nut. Position the tiller arms so they face toward the bottom of the rudder and forward towards the hinge line as shown. 8. Insert the hinges in the rudder. The T-pin will rest on the edge of the rudder bevel. B . Use side cutters to remove the plug from the clear light. Check the fit of the light in the tube in the rudder.
D . The wire can now be passed through the tube in the rudder. Proceed with hinging the rudder. 10. Saturate each hinge with thin CA. Apply CA to both the sides of the hinge. 9. Slide the rudder into position, guiding the hinges in the slots in the fin. Remove the T-pins from the hinges and slide the rudder tightly against the fin. Check that the rudder can move without rubbing the fin at the counter balance. 11.
E . Carefully solder the extension to the light. Use care not to melt the wiring by leaving the soldering iron in position too long. Make sure to stagger the solder joint so the wires will fit into the tube in the rudder. Use heat shrink tubing to protect the connections. Tail Wheel Installation 2. Apply 2–3 drops of thin CA in each of the holes to harden the surrounding wood. This will harden the threads so the screws do not easily strip the surrounding wood. 3.
Rudder and Elevator Servo and Linkage Installation 4. Use side cutters to remove the flat portion of the springs. Use pliers to bend the outermost coil at each end 90 degrees outward to form a hook. Required Parts Fuselage assembly Rudder pushrod Nylon clevis (3) Transmitter Receiver battery 2. Use a #1 Phillips screwdriver to thread a servo mounting screw into each of the holes to cut threads in the surrounding wood. Remove the screw before moving to the next step.
4. Prepare the rudder and elevator servo by installing the servo grommets and brass eyelets. 5. Install the rudder and elevator servos using eight servo mounting screws and a #1 Phillips screwdriver. 6. Insert the rudder pushrod into the tube in the fuselage. It is easiest to start from outside the fuselage when inserting the pushrod. 7. Slide the small piece of tubing in a nylon clevis. Thread the clevis 12-turns on the rudder pushrod wire.
8. Use a pin vise and 5/64-inch (2mm) drill bit to enlarge the hole in the servo horn. Enlarge the hole that is 1/2-inch (13mm) from the center of the horn as shown. Use side cutters to remove any unused arms so they don’t interfere with the operation of the servo. 10. Repeat steps 6 through 9 to install the elevator pushrod. Make sure to install a clevis for both elevator control horns 11.
Receiver Installation without Cockpit Kit Required Parts Fuselage assembly Receiver Y-harness Hook and loop tape 12-inch (305mm) servo extension (2) 3-inch (76mm) servo extension Required Tools and Adhesives Scissors 30 1. Use scissors to cut two small pieces of hook and loop tape the size of the receiver and remote receiver. Plug the rudder and elevator servos into the correct ports. Plug the 12-inch (305mm) extensions into the aileron and Aux 1 ports (this is used for differential aileron throw).
Servo Hatch Cover Installation Required Parts Fuselage assembly Servo hatch cover 2.5mm x 8mm washer-head self-tapping screw (4) 3. Apply 2–3 drops of thin CA in each of the holes to harden the surrounding wood. This will harden the threads so the screws do not easily strip the surrounding wood. Required Tools and Adhesives Thin CA Phillips screwdriver: #1 1. Route the servo leads for the ailerons and flaps outside the fuselage as shown.
2. Test fit the hardwood windscreen supports into position. The supports fit tightly at the top corners of the windscreen frame and meet at the bottom as shown. Use medium CA to glue the supports in position. 6. Apply 2–3 drops of thin CA in each of the holes to harden the surrounding wood. This will harden the threads so the screws do not easily strip the surrounding wood. 7. Install the upper window using four 2mm x 8mm self-tapping screws and a #1 Phillips screwdriver. 4.
8. Use medium CA to glue the seat supports in the fuselage. Make sure the CA has fully cured before proceeding. Cockpit Kit Installation (Optional) Required Parts Fuselage assembly Cockpit kit (optional) Required Tools and Adhesives Medium CA Two-sided tape You can use two-sided tape to secure the floor so it can be removed in the future, should a component need to be replaced or a repair to the airframe is necessary. 1. Test fit the pieces of the cockpit kit into the fuselage.
Wing and Wing Strut Installation Required Parts Wing panel (right and left) Fuselage assembly Nylon wing bolt (2) Wing strut, front (right and left) Jury strut fitting (4) Wing strut, rear (right and left) Jury strut, front (2) Jury strut, rear (2) Jury strut brace (2) Aluminum wing tube 4-40 lock nut (12) #4 washer (16) 4-40 x 1/2-inch socket head cap screw (4) 4-40 x 3/8-inch socket head cap screw (12) 34 2.
2. Install the threaded jury strut fitting in the wing so the threads are flush with the wing surface. 3. Slide the aluminum wing tube into the fuselage. Guide the flap and aileron extensions into the fuselage. The wing panel will fit tight against the fuselage as shown. 5. Temporarily attach the front and rear wing struts to the wing and wing strut tab. The airfoil of the struts will match the airfoil of the wing and the fitting on the wing strut will face toward the wing as shown in step 7.
6. Use two 4-40 x 1/2-inch socket head screws, two 4-40 lock nuts and two #4 washers to attach the jury struts to the strut fittings on the wing. The longer jury strut is closer to the flap while the shorter jury strut is toward the leading edge of the wing. Leave the hardware slightly loose so the position of the jury struts can be adjusted. 8. The jury struts will attach to the fittings on the wing strut closest to the fuselage.
2. Use side cutters to remove the plug from the clear light. Remove the end of the 36-inch (915mm) lighting extension. Cut the length of the lead so when the light is installed, the lead protrudes approximately 11/2-inches (38mm) from the wing root. Make sure the end that remains is the end that plugs into the lighting controller. Slide the extension through the tube into the wing root and out at the leading edge. 3. Carefully solder the extension to the light.
7. Repeat steps 1 through 3 to prepare and install the navigation light. When installing the navigation lights, the red will be on the left, and the green will be on the right. Leave the light extended out so it is visible in the navigation light cover when the cover is installed. 8. Install the navigation light cover using canopy glue. The fit should be tight, so tape will not be needed to hold the cover in position.
3. Use the template on page 45 to make the cover for the navigation light lens using adhesive backed Ultracote trim sheet. Center of Gravity Required Parts Assembled airframe Required Tools and Adhesives Felt-tipped pen Ruler Phillips screwdriver: #2 Balancing stand (optional) 3. When balancing your model, support the plane upright at the marks made on the bottom of the wing with your fingers or a commercially available balancing stand. This is the correct balance point for your model.
Control Throws 1. Turn on the transmitter and receiver of your model. Check the movement of the rudder using the transmitter. When the stick is moved right, the rudder should also move right. Reverse the direction of the servo at the transmitter if necessary. 2. Check the movement of the elevator with the radio system. Moving the elevator stick toward the bottom of the transmitter should make the airplane elevator move up. 3. Check the movement of the ailerons with the radio system.
Range Test Your Radio Before each flying session, and especially with a new model, it is important to perform a range check. It is helpful to have another person available to assist during the range check. If you are using a Spektrum transmitter, please refer to your transmitter’s manual for detailed instructions on the range check process. 1. With the model resting on the ground, stand 30 paces (approximately 90 feet) away from the model. 2.
Daily Flight Checks 1. Check the battery voltage of the transmitter battery. Do not fly below the manufacturer’s recommended voltage. To do so may cause your aircraft to crash. Limited Warranty What this Warranty Covers Horizon Hobby, Inc. (“Horizon”) warrants to the original purchaser that the product purchased (the “Product”) will be free from defects in materials and workmanship at the date of purchase.
Warranty Services Questions, Assistance, and Services Your local hobby store and/or place of purchase cannot provide warranty support or service. Once assembly, setup or use of the Product has been started, you must contact Horizon directly. This will enable Horizon to better answer your questions and service you in the event that you may need any assistance. For questions or assistance, please direct your email to productsupport@horizonhobby.com, or call 877.504.
Compliance Information for the European Union I nstructions for Disposal of WEEE by Users in the European Union This product must not be disposed of with other waste. Instead, it is the user’s responsibility to dispose of their waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment.
3. A t all flying sites a safety line(s) must be established in front of which all flying takes place (AMA Document #706-Recommended Field Layout): (a) Only personnel associated with flying the model aircraft are allowed at or in front of the safety line. (b) At air shows or demonstrations, a straight safety line must be established. (c) An area away from the safety line must be maintained for spectators. (d) Intentional flying behind the safety line is prohibited. 4.
Building and Flying Notes 46 E-flite Super Cub 25e ARF Assembly Manual
Building and Flying Notes E-flite Super Cub 25e ARF Assembly Manual 47
