T-28 Trojan Instruction Manual Bedienungsanleitung Manuel d’utilisation Manuale di Istruzioni
EN NOTICE All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, LLC. For up-to-date product literature, visit www.horizonhobby.com and click on the support tab for this product.
EN Box Contents Quick Start Information Blank (Acro) Model Servo Reversing: Rudder: Reverse Transmitter Elevator: Normal Setup Aileron: Reverse DO NOT Reverse Throttle Travel Adjust ( All Surfaces): 100% Ail Dual Rates Ele Rud Hi Rate Low Rate S=13mm T=13mm S=16mm T=16mm X=22mm W=22mm S=9.5mm T=9.5mm S=13mm T=13mm X=16mm W=16mm Center of Gravity (CG) 63.5mm back from leading edge at the root.
EN Preflight 1 Remove and inspect contents. 8 Bind the aircraft to your transmitter. 2 Read this instruction manual thoroughly. 9 Make sure linkages move freely. 3 Charge the flight battery. 10 Perform the Control Direction Test with the transmitter. 4 Fully assemble the airplane. 11 Adjust flight controls and transmitter. 5 Install the flight battery in the aircraft (once it has been fully charged). 12 Perform a radio system Range Test. 6 Check the Center of Gravity (CG).
EN Model Assembly Continued Landing Gear Installation A 1. Turn the model so the bottom of the wing faces up. 2. Install the main landing gear by inserting the main gear struts (A) into the corresponding gear plate hole located on each wing. 3. Carefully turn each strut in the gear plate until the horizontal section (B) of the strut gently snaps into place. 4. Loosen the nose gear screw (C) in the nose gear arm before installing the nose gear strut (D).
EN Model Assembly Continued Clevis Installation • Pull the tube from the clevis to the linkage. • Carefully spread the clevis, then insert the clevis pin into the desired hole in the control horn. • Move the tube to hold the clevis on the control horn. 1. 4. 2. 5. 3. 6. Control Surface Centering After assembly and transmitter setup, confirm that the control surfaces are centered. If the control surfaces are not centered, mechanically center the control surfaces by adjusting the linkages.
EN Transmitter and Receiver Binding Binding is the process of programming the receiver to recognize the GUID (Globally Unique Identifier) code of a single specific transmitter. You need to ‘bind’ your chosen Spektrum™ DSM2®/DSMX® technology equipped aircraft transmitter to the receiver for proper operation. IMPORTANT: Before binding a transmitter, read the Transmitter Setup section of this manual to ensure that your transmitter is properly programmed for this aircraft.
EN Battery Installation and ESC Arming Battery Selection A We recommend the E-flite® 1800mAh 11.1V 3S 30C Li-Po battery (EFLB18003S30). Refer to the Optional Parts List for other recommended batteries. If using a battery other than those listed, the battery should be within the range of capacity, dimensions and weight of the E-flite Li-Po battery packs to fit in the fuselage. Be sure the model balances at the recommended CG. 1.
EN Control Direction Test Bind your aircraft and transmitter before performing these tests. Move the controls on the transmitter to ensure the aircraft control surfaces move correctly. After doing the Control Test, correctly set the failsafe. Make sure the transmitter controls are at neutral and the throttle and throttle trim are in the low position, then rebind the model to your transmitter.
EN Flying Tips and Repairs Consult local laws and ordinances before choosing a flying location. Flying Field Always choose a wide-open space for flying your aircraft. It is recommended that you fly at a designated RC flying field. Always avoid flying near houses, trees, wires and buildings. Avoid flying in areas where there are many people, such as parks, schoolyards, or soccer fields. Range Check your Radio System Before you fly, range check the radio system.
EN Motor Service CAUTION: Always disconnect the flight battery before performing motor service. A C D B F Disassembly 1. 2. 3. 4. Use a tool to remove the spinner nut (A) from the collet (B). Remove the propeller (C), backplate (D) and collet from the motor shaft. Remove three screws (E) from the cowling (F). Carefully remove the cowling from the fuselage. Paint may keep the cowling attached to the fuselage. 5. Remove four screws (G) from the motor mount (H) and fuselage. 6.
EN Troubleshooting Guide Problem Aircraft will not respond to throttle but responds to other controls Extra propeller noise or extra vibration Reduced flight time or aircraft underpowered Aircraft will not Bind (during binding) to transmitter Aircraft will not connect (after binding) to transmitter Possible Cause Throttle not at idle and/or throttle trim too high Reset controls with throttle stick and throttle trim at lowest setting Throttle servo travel is lower than 100% Make sure throttle servo t
EN AMA National Model Aircraft Safety Code Effective January 1, 2014 A. GENERAL A model aircraft is a non-human-carrying aircraft capable of sustained flight in the atmosphere. It may not exceed limitations of this code and is intended exclusively for sport, recreation, education and/or competition. All model flights must be conducted in accordance with this safety code and any additional rules specific to the flying site. 1. Model aircraft will not be flown: (a) In a careless or reckless manner.
EN Limited Warranty What this Warranty Covers Horizon Hobby, LLC, (Horizon) warrants to the original purchaser that the product purchased (the “Product”) will be free from defects in materials and workmanship at the date of purchase.
EN Contact Information Country of Purchase Horizon Hobby Horizon Service Center (Repairs and Repair Requests) United States of America Horizon Product Support (Product Technical Assistance) Sales United Kingdom Germany France China Service/Parts/Sales: Horizon Hobby Limited Horizon Technischer Service Sales: Horizon Hobby GmbH Service/Parts/Sales: Horizon Hobby SAS Service/Parts/Sales: Horizon Hobby – China Phone Number/Email Address servicecenter.horizonhobby.com/ RequestForm/ www.quickbase.
