Manual

Operating instructions
D1G133-DC13-52
Translation of the original operating instructions
3.2 Nominal data
Motor M1G074-CF
Nominal voltage / VDC 24
Nominal voltage
range / VDC
16 .. 28
Frequency / Hz -
Type of data definition fa
Speed / min
-1
1580
Power input / W 118
Current draw / A 6.0
Min. ambient temperature
/ °C
-25
Max. ambient
temperature
/ °C
60
ml = Max. load · me = Max. efficiency · fa = Running at free air
cs = Customer specs · cu = Customer unit
Subject to alterations
3.3 Technical features
Mass 3.46 kg
Size 133 mm
Surface of rotor Coated in black
Material of impeller Sheet steel, hot-galvanised
Housing material Sheet steel, hot-galvanised
Motor suspension Motor anti-vibration mounted on both sides
Direction of rotation Clockwise, seen on rotor
Type of protection IP 42
Insulation class "B"
Humidity class F0
Mounting position Any
Condensate discharge
holes
None
Operation mode S1
Motor bearing Ball bearing
Technical features - Control input 0-10 VDC / PWM
- Tach output
- Motor current limit
- Soft start
Motor protection Reverse polarity and locked-rotor
protection
Cable exit Variable
Product conforming
to standard
EN 60950-1
Approval CSA C22.2 Nr.77; EAC; UL 1004-1
For cyclic speed loads, note that the rotating parts of the device
are designed for maximum one million load cycles. If you have
specific questions, contact ebm-papst for support.
3.4 Mounting data
For depth of screw, see chapter 3.1 Product drawing
; Secure the mounting screws against accidentally coming loose (e.g.
by using self-locking screws).
Strength class for
mounting screws
8.8
You can obtain additional mounting data from the product drawing if
necessary.
3.5 Transport and storage conditions
; Use the device in accordance with its protection type.
Max. permissible
ambient motor temp.
(transp./ storage)
+ 80 °C
Min. permissible
ambient motor temp.
(transp./storage)
- 40 °C
3.6 Electromagnetic compatibility
EMC interference
immunity
Acc. to EN 61000-6-2 (industrial
environment)
EMC interference
emission
Acc. to EN 55022 (Class B)
Item no. 51000-5-9970 · Revision 82545 · Release 2014-05-08 · Page 5 / 9
