User Manual

Operating instructions
K3G280-AT04-74
Translation of the original operating instructions
3. TECHNICAL DATA
3.1 Product drawing
All measures have the unit mm.
1 Bleeder connection for pressure relief (k-value 93)
2 Connection line AWG18, 5 x crimped core-end sleeves
3 Connection line AWG22, 3 x crimped core-end sleeves
