HEDGE CLIPPER OPERATOR'S MANUAL Shaft Hedge Clipper Operator's Manual MODELS: SHC-1700 - Type 1 SHC-1700 - Type 1E SHC-2100 - Type 1 SHC-2100 - Type 1E SHC-2400 - Type 1 SHC-2400 - Type 1E HCA-2400 - Type 1E - S/N 001001 & Up - S/N 501001 - 504767 - S/N 001001 & Up - S/N 501001 - 506455 - S/N 001001 & Up - S/N 00501001 &Up - S/N 00501001 &Up WARNING The engine exhaust from this product contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm.
INTRODUCTION Welcome to the ECHO family. This ECHO product was designed and manufactured to provide long life and on-the-jobdependability. Read and understand this manual and the SAFETY MANUAL you found in the same package. You will find both easy to use and full of helpful operating tips and SAFETY messages. WARNING DANGER Read rules for safe operation and instructions carefully. ECHO provides an Operator's Manual and a Safety Manual. Both must be read and understood for proper and safe operation.
HEDGE CLIPPER OPERATOR'S MANUAL MANUAL SAFETY SYMBOLS AND IMPORTANT INFORMATION Throughout this manual and on the product itself, you will find safety alerts and helpful, information messages preceded by symbols or key words. The following is an explanation of those symbols and key words and what they mean to you. This symbol accompanied by the words WARNING and DANGER calls attention to an act or condition that can lead to serious personal injury to operator and bystanders.
DECALS, WARNING/INFORMATIONAL Locate these safety decals on your unit. The complete unit illustration found in the "DESCRIPTION" section, will help you locate them. Make sure the decals are legible and that you understand and follow the instructions on them. If a decal cannot be read, a new one can be ordered from your ECHO dealer. See PARTS ORDERING instructions for specific information.
HEDGE CLIPPER OPERATOR'S MANUAL EQUIPMENT Before operation a complete check of the unit must be performed; - Check unit for loose/missing nuts, bolts and screws. Tighten and/or replace as needed. - Inspect fuel lines, tank and area around carburetor for fuel leaks. DO NOT operate unit if leaks are found. - Inspect hand guard for damage. Replace if damaged or missing. - Check that the blade assembly is firmly attached and in safe operating condition. Dull, loose or damaged blades should not be used.
PERSONAL CONDITION AND SAFETY EQUIPMENT WARNING DANGER Hedge Clipper users risk injury to themselves and others if the shaft hedge clipper is used improperly and or safety precautions are not followed. Proper clothing and safety gear must be worn when operating a shaft hedge clipper. Physical Condition Your judgment and physical dexterity may not be good: - if you are tired or sick, - if you are taking medication, - if you have taken alcohol or drugs.
HEDGE CLIPPER OPERATOR'S MANUAL Hot Humid Weather Heavy protective clothing can increase operator fatigue which may lead to heat stroke. Schedule heavy work for early morning or late afternoon hours when temperatures are cooler. SAFE OPERATION Determine Operation Area - Review the area to be trimmed. Look for hazards that could contribute to unsafe conditions. DO NOT operate unit if any wires (power, telephone, cable, etc.) are closer than 15 feet (4.6 meters) to any part of the operator or unit.
Operation (HCA) - Never adjust blade angle of HCA while standing. - Only adjust cutting angle with HCA resting flat on the ground, with the engine stop switch in the "STOP" position. - Adjust cutting angle by moving locking lever (A) up. Depress blade indexing lever (B) and change blade angle with rear cutter assembly handle. Release indexing lever (B) into notch. Move locking lever (A) down to completely engage internal gears. IMPORTANT Lever (A) does not secure gearbox angle setting.
HEDGE CLIPPER OPERATOR'S MANUAL To reduce the risk of RSI/CTS, do the following: • Avoid using your wrist in a bent, extended or twisted position. Instead try to maintain a straight wrist position. Also, when grasping, use your whole hand, not just the thumb and index finger. • Take periodic breaks to minimize repetition and rest your hands. • Reduce the speed and force with which you do the repetitive movement. • Do exercises to strengthen the hand and arm muscles.
1 2 SHC-1700 4 3 6 9 20 19 8 SHC-2100 4 3 6 9 20 19 8 SHC-2400 6 3 9 19 14 5 20 4 22 21 HCA-2400 20 9 3 7 6 5 8 18 23 SHC-1700, 2100 POWERHEAD 16 16 12 SHC-2400, HCA-2400 POWERHEAD 12 10 17 17 11 10 11 15 14 13 14 24 15 13
HEDGE CLIPPER OPERATOR'S MANUAL 11 1. SAFETY MANUAL - Read and understand this manual before operation. Keep manual in a safe location as a reference for safe operating techniques. 2. OPERATOR'S MANUAL - Read and understand this manual before operation. Keep manual in a safe location for future reference, i.e., operation, maintenance, storage and specifications. 3. POWER HEAD - Factory Assembled. Includes the Engine, Clutch, Fuel System, Ignition System and Starter. 4.
SPECIFICATIONS MOD EL SH C -1700 TYPE 1 SH C -1700 TYPE 1E SH C -2100 TYPE 1 SH C -2100 TYPE 1E SH C -2400 TYPE 1 SH C -2400 TYPE 1E H C A-2400 TYPE1E Length 1335 mm (52.5 i n.) 1816 mm (71.5 i n.) 2190 mm (86.3 i n.) 2034 mm (80.1 i n.) Wi dth 216 mm (8.5 i n.) 216 mm (8.5 i n.) 216 mm (8.5 i n.) 225 mm (8.9 i n.) Hei ght 235 mm (9.3 i n.) 235 mm (9.3 i n.) 229 mm (9.0 i n.) 223 mm (8.8 i n.) Wei ght (dry) 5.5 kg (12.1 lb.) 5.6 kg (12.3 lb.) 5.7 kg (12.6 lb.) 6.2 kg (13.7 lb.
HEDGE CLIPPER OPERATOR'S MANUAL 13 ASSEMBLY (HCA-2400, SHC-2100, 2400) SHC-1700 is Factory Assembled in the box. Gear Box/Drive Shaft (SHC-2100, 2400, HCA-2400) SHC-1700, 2100, 2400 Tools Required: 8MM Open End Wrench, Screwdriver Parts Required: Power Head/Drive Shaft Assembly and Gear Box/Blade Assembly. NOTE Hedge Clipper Blades are very sharp. Wear gloves to protect hands. 1. Slide the Gear Housing Assembly on the Drive Shaft. Be certain the Flex Drive Shaft engages the hole in Driver Gear. 2.
PRE-OPERATION FUEL Fuel Requirements Gasoline - Use 89 Octane [R +2 M ] (mid-grade or higher) gasoline or gasohol known to be good quality. Gasohol may contain up to 10% Ethyl (grain) alcohol or 15% MTBE (methyl tertiary-butyl ether). Gasohol containing methanol (wood alcohol) is NOT approved. Two Stroke Oil - A two-stroke engine oil meeting ISO-L-EGD Standard (ISO/CD 13738), must be used. Echo brand Premium 50:1 oil meets this standard.
HEDGE CLIPPER OPERATOR'S MANUAL IMPORTANT Stored fuel ages. Do not mix more fuel than you expect to use in thirty (30) days, ninety (90) days when a fuel stabilizer is added. IMPORTANT Stored two-stroke fuel may separate. ALWAYS shake fuel container thoroughly before each use. S M 1 2 8 9 15 16 22 23 29 30 EQUIPMENT CHECK Before operation a complete check of the unit must be performed; - Check unit for loose/missing nuts, bolts and screws. Tighten and/or replace as needed.
OPERATION (SHC Models) 50 FT. (15 M) - Before starting the unit, equip yourself and any other person working within the 50 ft. (15 M) Safety Zone with the required Protective Equipment and clothing. - During operation, the complete unit, especially the gear box, drive shaft housing and power head muffler area may become very hot, too hot to touch. Avoid contact during and immediately after operation.
HEDGE CLIPPER OPERATOR'S MANUAL 17 STARTING COLD ENGINE WARNING DANGER Blades should not move at idle. If blades move, readjust carburetor according to Carburetor Adjustment instructions in the manual or see your ECHO dealer, otherwise serious personal injury may result. 1. Ignition Switch - Start/Run. (All Models) Move Ignition Switch lever/ button away from the STOP position. 2. Close Choke - Cold Start. - SHC-1700, 2100 -Push choke lever forward to Cold Start.
STARTING WARM ENGINE The starting procedure is the same as Cold Start except DO NOT close the choke. NOTE If engine does not start after 4 pulls, use Cold Start Procedure. HCA-2400 WARNING DANGER Blades should not move at idle. If blades move, readjust carburetor according to Carburetor Adjustment instructions in the manual or see your ECHO dealer, otherwise serious personal injury may result. 1. Ignition Switch - Start/Run.
HEDGE CLIPPER OPERATOR'S MANUAL STOPPING ENGINE (SHC UNITS) 1. Release Throttle. Allow engine to idle for a minute 2. Ignition Switch - STOP. Move ignition switch toggle/slide switch to STOP position. NOTE SHC-1700, 2100 with front handle interlock will automatically shut unit off when released. WARNING DANGER If engine does not stop when stop switch is moved to STOP position, close choke - COLD START position - to stall engine.
MAINTENANCE Your ECHO product is designed to provide many hours of trouble free service. Regular scheduled maintenance will help achieve that goal. If you are unsure or are not equipped with the necessary tools, you may want to take your unit to an ECHO Service Dealer for maintenance. To help you decide whether you want to DO-IT-YOURSELF or have the ECHO Dealer do it, each maintenance task has been graded. If the task is not listed, see your ECHO Dealer for repairs.
HEDGE CLIPPER OPERATOR'S MANUAL AIR FILTER Level 1. Tools required: Cleaning brush, 1" or 2" medium bristle paint brush. Parts required: (SHC Models) 90008 REPOWERTM AIR & FUEL FILTER KIT. (HCA-2400) 90030 REPOWERTM AIR & FUEL FILTER KIT. 1. Close choke (Cold Start Position). This prevents dirt from entering the carburetor throat when the air filter is removed. Brush accumulated dirt from the air cleaner area. 2. Remove the air cleaner cover. Clean and inspect the element for damage.
SPARK PLUG Level 2. Tools Required: T-Wrench. Feeler gauge. Preferably a wire gauge. Brush. Parts Required: Spark Plug, Champion CJ-7Y or NGK BPM-7A 1. Remove spark plug and check for fouling, worn and rounded center electrode. 2. Clean the plug or replace with a new one. DO NOT sand blast to clean. Remaining sand will damage engine. 3. Adjust spark plug gap by bending outer electrode. 0.65 mm (0.026 in.
HEDGE CLIPPER OPERATOR'S MANUAL Spark Arrestor Screen 1. Remove screen holder and gasket from muffler body. 2. Clean carbon deposits from screen and muffler components. 3. Replace screen if it is cracked, plugged or has holes burned through. COOLING SYSTEM CLEANING Level 3. Tools required: Cross Head Screwdriver, 3 mm Hex wrench, 4 mm Hex wrench, Pointed Wood Stick, Cleaning Brush, 1"-2" medium bristle paint brush. Parts Required: None.
3. Use the wooden stick or brush to remove dirt from the cylinder fins. 4. Remove grass and leaves from the grid between the recoil starter and fuel tank. 5. When installing the engine cover, be certain the tab of the metal deflector shield is in the slot of the cover. CARBURETOR ADJUSTMENT Type 1E Models Level 2. Tools required: Screwdriver, Tachometer (ECHO P/N 99051130017). Parts required: None.
HEDGE CLIPPER OPERATOR'S MANUAL 7. Check idle speed and reset if necessary. If a tachometer is available, idle speed should be set to the specification found on page 12 "Specifications" of this manual. WARNING 25 C DANGER When carburetor adjustment is completed, blades should not move at idle, otherwise serious personal injury may result.
c. Final setting - Set needle at mid point between lean rich drop-off points. (3) d. Turn 1/8 turn CCW (out) making mixture slightly richer. (4) 3. 4. High speed adjustment. Adjust HI needle (A) with tachometer to achieve the specifications found on page 12 "Specifications" of this manual. (3) (4) (2) (1) Check idle speed and reset if necessary. Using a tachometer, idle speed should be set to the specification found on page 12 "Specifications" of this manual.
HEDGE CLIPPER OPERATOR'S MANUAL 27 SHC-1700, 2100, 2400, HCA-2400 Tools required: Grease Gun with Lithium Grease, Rag. SHC-1700, 2100, 2400 Parts required: Lithium Based Grease. 1. Clean dirt from grease fittings. 2. Carefully pump grease in each fitting. DO NOT force grease. Too much pressure will force grease past seals and cause damage. Apply 1-2 pumps of grease every 15-20 hours of operation.
SHARPENING BLADES Level 1. Tools required: Flat file, Small Screwdriver Parts required: Gear Box gasket, Lithium Based Grease. NOTE Blade sharpening requires removal of blades from the unit. Step by step instruction are included in the Service Manual that apply to your model. NOTE Hedge Clipper Blades are very sharp. Wear gloves to protect hands. 1. 2. Use screwdriver to separate upper and lower cutters equal distance apart. File each edge carefully. Follow the original shape of the blade.
HEDGE CLIPPER OPERATOR'S MANUAL 4. Remove the old starter rope and prepare the new rope by first heating both ends to prevent fraying. 5. Pass one end of the rope through the opening of the drum and tie a knot. Press knot and end of rope in cavity of drum. 6. Thread the rope through the eyelet in the housing (C) then through the starter handle (D). Follow the illustration and tie another knot in the free end of the rope. Pull the knot into the handle. D C 7.
9. Install drum. The loop in the spring must engage the slot in the drum. Replace the screw and washer. 10. Hold the rope in the notch (H) and rotate the drum counterclockwise several turns. 11. Hold the drum to prevent it from rewinding, pull the excess rope taught with the handle and allow to rewind slowly. H 12. Pull rope several times to check spring tension. If rope does not rewind fully, repeat step 10. 13. Pull rope out all the way.
HEDGE CLIPPER OPERATOR'S MANUAL 3. Remove accumulation of grease, oil, dirt and debris from exterior of unit. 4. Perform all periodic lubrication and services that are required. 5. Tighten all the screws and nuts. 6. Drain the fuel tank completely and pull the recoil starter handle several times to remove fuel from the carburetor. 7. Remove the spark plug and pour 1/4 oz. (1/2 tablespoon) of fresh, clean, two-stroke engine oil into the cylinder through the spark plug hole. A. B. C. 8.
SERVICING INFORMATION PARTS Genuine ECHO Parts and ECHO REPOWER™ Parts and Assemblies for your ECHO products are available only from an Authorized ECHO Dealer. When you do need to buy parts always have the Model Number, Type number and Serial Number of the unit with you. You can find all three numbers on the engine housing. For future reference, write them in the space provided below. Model No. _____________ Type No. _________SN.
