2006 CATALOGUE Music Driving On 2006 Mobile Entertainment Catalogue
In a class all its own. 2 Usability Originality Quality Emphasising the ease of use that so distinguishes ECLIPSE products, the attractive control interface reduces the number of controls, intelligently assigning all operations to a few controls for easier, intuitive operation for any navigation or audio/visual task.
Introducing a system that delivers audio, visual and navigation in an elegant all-in-one design. It integrates easily into any car’s interior — there is simply no other product like it.
AV Navigation Fitting elegantly into the centre console to enhance a car’s interior. Navigation Ultima Engine 20GB 1.8˝ HDD 7˝ (175mm) wide TFT display with touch control over 32,000 map colours 334 3D landmarks approx. 11,000 landmarks • Multiple search modes • Split screen displays • Map scale from 50m to 500km • Voice announcements and guidance (10 languages) • Time zones (Greenwich, Central and East) • Border guidance Advanced navigation with outstanding ease of use.
The technology inside The challenge was to fit an immense amount of technology into a space-limited one-DIN unit housing. By extensively employing the latest advances in integrated circuit technologies, ECLIPSE was able to achieve an impressive engineering feat of fitting all the technology in. ECLIPSE is the only mobile electronics manufacturer to offer so much in a single, compact enclosure.
Searching Offering the most convenient ways to find your destination. Define search area Conveniently focuses on a general region for more efficient searching. Motorway search Simplifies highway travel. All searching starts with selecting the country the destination is in. Just input the name of a motorway and the entrance/exit you want. Quick access points 5 buttons can be preset to any desired destination for instant recall. Coordinates search Home search Searches by latitude and longitude.
Routing Always a useful choice of routes for the user to choose from. Road preference 3 routes Instantly sets three routes no matter the destination. For any destination, a choice of Quick 1, Quick 2 and Short routes to suit personal preferences adds flexibility. Preset travel method preferences such as motorways and toll roads are factored into the routes the the user can choose from. Enroute stopping points Choose when and where to take breaks.
Assistance Comprehensive help features make driving enjoyable. Voice announcements and guidance Auto rerouting Motorway assistance No more missed turns. Instant response ensures no wasted time. Entrance displays Wrong turns and missed streets are no longer a problem because the AVN8826 instantly reroutes to put the user right back on track. New route Original route For stress-free driving, the AVN8826 advises upcoming turns and will continue to warn as the turn approaches.
Special display Making navigation easier than ever to use. features The navigational database contains a substantial number of POIs that assist finding various locations. Petrol stations and restaurants are only some of the useful categories of POIs. Each category is also assigned a distinctive icon. For more information about a specific icon, simply press it to display pertinent information such as telephone number, address and so forth.
Transport yourself into a theatre environment.
DCU105 Audio Video Matrix ECLIPSE designed the powerful Audio Video Matrix unit that can be used with various ECLIPSE products. Because it is a dedicated unit, the addition of the DCU105 elevates the performance of unit it is connected to significantly for audio as well as video. It offers system control and response that would ordinarily require technicians and test equipment to achieve. It also offers many advanced system expansion choices for audio as well as video. Dolby Digital 5.1 ch. dts 5.1 ch.
Audio High-end performance comparable to dedicated components. AVN8826 + DCU105 — Precision tonal contouring for accurate sound. AVN8826 Normal Mode Perform easy audio customisation using the AVN8826 by itself. Parametric EQ Pro The professional EQ method for tuning a system’s frequency response because of its absolute versatility and precision control. It smoothes out system response, eliminating troublesome frequency peaks and dips.
Enables optimal listening. Listening Position Selector This function compensates for any seating position, optimising system response for that position as if it was in the perfect sweet spot for listening as in a home audio system. For adjusting the overall system-wide balance. Fader and Balance Easy directional controls and a visual indicator make it easy to set system-wide balance in any direction to suit user preferences.
Full-featured entertainment technology that satisfies. Whatever you choose to make driving more enjoyable, music or video, the AVN8826 offers the specialised functions and features that make sure you get the best performance. Versatile 7˝ (175mm) wide display Responsive to a fingertip touch, the sharp TFT display provides high resolution viewing optimised for navigation as well as DVD-Video. For entertainment viewing, the aspect ratio can be switched to any of four settings as desired.
Features List Media HDD DVD CD Memory Stick Duo Navigation Navi Device HDD Navigation Ultima Engine Displaying Display Map colours Split screen Street name Point-of-Interest (POI) Landmark 2D/3D Operation Touch-Panel control Searching Address search POI search POI near search Map search Memory search Previous search Intersection search Motorway search (ENTER/EXIT) Coordinates search Telephone number search Home search Quick access point search Routing 3 routes information Detours Enroute stopping points Rou
Honouring the music. Dedicated performers that please music lovers. ECLIPSE CD Receivers are fully self-contained with 4-channel power amplification and designed to provide the maximum performance from optical disc sources. The series is constantly being refined with new technologies and important new features.
CD Receivers Offering all that is required to communicate music in the best way. Overengineered construction, premium components and advanced digital and analogue circuits work in harmony to produce superb sound. Both the CD8445E and CD5425E are exceptional head units that deliver the best possible reproduction from today’s popular music program formats — CD, CD-R/RW, and MP3, with the CD8445E also compatible with WMA files. Either model will satisfy discerning music lovers.
Audio customise The CD8445E offers the most comprehensive customisation functions for a user to optimise an audio system for the specific car it is installed in. In addition, customisation can be performed in two modes: Professional Mode and Easy Mode. Professional Mode offers a degree of user customisation that would normally require test equipment and qualified personnel to perform, while Easy Mode intelligently groups related parameters to simplify adjustment.
High-voltage preamp output ECLIPSE audio philosophy emphasises high performance so both the CD8445E and CD5425E are designed to deliver ideal electrical characteristics. Doing so allows downstream amplifiers to be driven optimally to deliver the best performance with minimal noise and distortion. CD8445E: 8V at 55Ω, CD5425E: 5V at 55Ω 3-Band EQ This feature was designed to allow a user to easily adjust the tonal characteristics of program material to suit listening preferences.
Specifications Feature List CONTROL Remote Control CD Changer Control CD-R/CD-RW WMA MP3 Digital Servo System (DSS) TUNER FM/MW/LW RDS Tuner AUDIO Output Voltage and Impedance MOSFET Amplifier Advanced 24-Bit ∆∑ DAC Source Volume Control (SVC) Sound Control Mode Circle Surround II Bass/Mid/Treble Control Time Alignment Parametric EQ Multi-Harmonizer (MP3/WMA/ATRAC3) Listening Position Selector Crossover Non Fader Level / Phase Control Frequency Response Analysis 3-band Graphic EQ Dual Pre Outputs Non-Fader
